Uzglabāšanas temperatūras amplitūda (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 60
-
Iepakojuma svars:
Weight of the packaged product.
-
356.1 g
-
Darbības temperatūras amplitūda (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-20 - 60
-
Kabeļa garums:
How long the cable is.
-
100 m
-
Kabeļa tips:
Type of cable e.g. electicity cable, optical cable.
-
SC/UPC
-
Datu pārsūtīšanas ātrums:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
100 Gbit/s
-
Produkta krāsa:
The colour e.g. red, blue, green, black, white.
-
Dzeltens
-
Iepakojuma dziļums:
The distance from the front to the back of the packaging.
-
280 mm
-
Iepakojuma augstums:
The distance from the top to the bottom of the packaging.
-
18 mm
-
Iepakojuma platums:
The distance from one side of the packaging to the other.
-
280 mm
-
Oriģinālās kastes augstums:
-
280 mm
-
Oriģinālās kastes platums:
-
380 mm
-
Savienotājs 1:
This is the first connector in the device.
-
SC
-
Savienotājs 2:
This is the second connector in the device.
-
SC
-
Kabeļa diametrs:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
2 mm
-
Ievietošanas zudums:
-
0.3 dB
-
Šķiedras režīma struktūra:
-
Viens režīms
-
Vidus diametrs:
The diameter of the core, which is the material at the centre e.g. the metal in an electrical wire.
-
9 µm
-
Apšuvuma diametrs:
The diameter of the cladding, which is the material around the centre (core) e.g. the plastic coating in an electrical wire.
-
125 µm
-
Jakas materiāls:
-
Polipropilēns, Ar neliela dūmu daudzuma izdalīšanos degšanas gadījumā, bez halogēna (LSZH)
-
Konektora 1 tips:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Sieviete
-
Konektora 2 tips:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Vīrietis
-
Lieces rādiuss:
-
10 mm
-
Skaits iepakojumā:
-
1 pcs
-
Atbalstītie viļņu garumi:
-
1600, 1280, 1550, 1300, 1590, 1310, 1383, 1625, 1260, 1490
-
Samazinājums (maks.):
-
0.35 dB/km
-
Kastes garums (Master):
-
380 mm
-
Daudzums Master kastē:
-
20 pcs
-
Optiskās šķiedras veids:
The standardised properties of the fiber optic cable.
-
OS2
-
Atgriezeniskie zudumi:
-
55 dB
-
Ilgtspējas atbilstība:
-
Jā
