Monitor Elo Touch Solutions 2402L

Name: Monitor Elo Touch Solutions 2402L E126288
Brand: Elo Touch Solutions
SKU: 11017412
Price: 618.99 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Monitor Elo Touch Solutions 2402L 23.8" Touchscreen LCD 1920 x 1080

Monitor Elo Touch Solutions 2402L Photo 1

Monitor Elo Touch Solutions 2402L Photo 2

Monitor Elo Touch Solutions 2402L Photo 3

Monitor Elo Touch Solutions 2402L Photo 4

Monitor Elo Touch Solutions 2402L Photo 5

Monitor Elo Touch Solutions 2402L Photo 6

Product data

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Offer for legal entity, cashless payment. Why is an item available only for a legal entity?
This is due to long delivery times and limited product warranties.

Short description

The Elo Touch Solutions 2402L is a 23.8" LCD touchscreen monitor with a Full HD resolution of 1920 x 1080 pixels. It features a brightness of 250 cd/m², providing clear and vibrant visuals. The sleek black design makes it suitable for various environments. Ideal for interactive applications, this monitor ensures responsive touch capabilities, enhancing user experience.

Available at price 618.99 €: 39 pcs.

Total available for order: 94 pcs.

Warranty: 2 Years

SKU: 11017412

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

29.06.2026 {{selectedOffer.courierDeliveryString}}

From 6.60 € (Weight: 7.30 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

29.06.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Leasing for legal entities

Find out more Hide details

Leasing for legal entities: from 21.54 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Elo 2402L is a 23.8" touchscreen LCD monitor from the Elo 02-Series offering a Full HD 1920 x 1080 resolution in a compact, flat design. Built with Elo's TouchPro® projected capacitive touch technology, the monitor provides up to 10-point touch capability, wide viewing angles and clear image transmission. Its slim black housing and VESA compatibility allow integration in point-of-sale, information and hospitality environments. The display includes built-in speakers and meets Elo's reliability standards with a standard three-year warranty and optional extension.

Advantages

The 23.8" Elo 2402L combines responsive multi-touch performance with Full HD clarity and a compact form factor for flexible placement. TouchPro® PCAP glass ensures accurate touch response and good light transmission for vivid images, while up to 10 simultaneous touches deliver a tablet-like interaction. The monitor supports multiple mounting options and a range of Elo Edge Connect peripherals that can be attached to the touchscreen edge to create tailored solutions.

Suitable for

Point-of-sale terminals and retail checkout counters
Self-service kiosks and restaurant ordering stations
Information terminals and digital signage in public areas
Hospitality check-in desks and guest interactions

Key specifications

Display diagonal: 23.8"
Resolution: 1920 x 1080 (Full HD)
Panel type: TFT LCD
Touch technology: TouchPro® projected capacitive (up to 10 touches)
Brightness: 250 cd/m²
Contrast ratio (typical): 1000:1
Response time: 15 ms
VESA mounting: Yes
Built-in speakers: Yes
Colour: Black
Warranty: 3 years standard (optional extension available)

How to use

Mount the monitor using the supplied stand or any compatible VESA mount for the desired installation (counter, wall or pole). Connect power and display/data interfaces according to the Elo 2402L user manual, and calibrate touch if required by the host system. Attach Elo Edge Connect peripherals at the touchscreen edge when additional devices (card readers, scanners, customer displays) are needed. Use the on-screen menu to adjust brightness, contrast and audio settings for the installation environment.

Usage recommendations

For reliable long-term operation, install the monitor in a dry, dust-reduced environment, avoid direct sunlight on the panel to maintain image visibility, and follow Elo's calibration and cleaning instructions for PCAP glass. Consider the optional warranty extension for deployments with high usage or public access.

Specifications

Display diagonal: iagonal of the visible part of the screen expressed in centimeters and inches.: 23.8 "
Display resolution:: 1920 x 1080
HD type:: Full HD
Panel type:: TFT
Display technology:: LCD
Response time:: 15 ms
Contrast ratio (typical):: 1000:1
Screen shape:: Flat
VESA mounting:: Yes
Built-in speaker(s):: Yes
Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.: E
Energy consumption (SDR) per 1000 hours: Power consumption in switched-on state expressed in W.: 17 kWh
Product colour:: Black

All features

Display

Display diagonal: iagonal of the visible part of the screen expressed in centimeters and inches.: 23.8 "
Display technology:: LCD
HD type:: Full HD
Panel type:: TFT
Display resolution:: 1920 x 1080
Response time:: 15 ms
Contrast ratio (typical):: 1000:1
Display brightness:: 250 cd/m²
Viewing angle, vertical:: 178 °
Viewing angle, horizontal:: 178 °
Supported graphics resolutions:: 1680 x 1050 (WSXGA+), 1440 x 900 (WXGA+), 1366 x 768, 1280 x 800 (WXGA), 1920 x 1080 (HD 1080), 1280 x 1024 (SXGA), 1024 x 768 (XGA), 800 x 600 (SVGA), 720 x 400, 640 x 480 (VGA), 640 x 400, 1280 x 720 (HD 720)
Native aspect ratio:: 16:9
Display number of colours:: 16.78 million colours
Touchscreen:: Yes
LED backlight:: Yes
Touchscreen technology:: Projected capacitive system
Number of simultaneous touchpoints:: 10

Design

Screen shape:: Flat
Product colour:: Black
Panel mounting interface:: 100 x 100, 75 x 75

Ports & interfaces

HDMI ports quantity:: 1
Micro-USB ports quantity:: 4

Ergonomics

VESA mounting:: Yes

Audio

Built-in speaker(s):: Yes

Performance

Mean time between failures (MTBF):: 50000 h
On Screen Display (OSD) languages:: CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, RUS
Number of OSD languages:: 10

Multimedia

RMS rated power:: 4 W
Built-in camera:: No

Other features

Headphone outputs:: 1
Maximum refresh rate:: 60 Hz
Digital horizontal frequency:: 30 - 82
Digital vertical frequency:: 50 - 75
Power supply type:: AC/DC
Certification:: Canada (CUL,IC), China CCC, Europe CE, Korea KCC, Taiwan BSMI, United States (FCC,UL), Japan VCC, Internationa lCB, Australia RCM, Russia EAC, Mexico CoC
Display viewable area (HxV):: 527 x 296.5
AC adapter included:: Yes
Quick start guide:: Yes
International Protection (IP) code: Device protection rating against dust and water according to the international IP standard.: IPX1
Weight (without stand):: 5420 g
Height (without stand):: 337.2 mm
Depth (without stand):: 42.8 mm

Power

Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.: E
Energy consumption (SDR) per 1000 hours: Power consumption in switched-on state expressed in W.: 17 kWh
Power consumption (typical): Power consumption in switched-on state expressed in W.: 25.5 W
Power consumption (off):: 0.27 W
Power consumption (standby):: 0.33 W
AC input frequency:: 50 - 60
AC input voltage:: 100 - 240
Energy efficiency scale: Range of energy efficiency levels classifying devices from most to least energy-efficient.: A to G

Operational conditions

Operating altitude:: 0 - 3.05
Operating relative humidity (H-H):: 20 - 80
Storage temperature (T-T):: -20 - 60
Operating temperature (T-T):: 0 - 40
Storage relative humidity (H-H):: 10 - 95
Non-operating altitude:: 0 - 12.2

Packaging content

Cables included:: HDMI, AC, VGA, USB, Audio (3.5mm)
Stand included:: No

Packaging data

Package weight:: 7540 g
Package depth:: 169 mm
Package height:: 460 mm
Package width:: 680 mm

Logistics data

Harmonized System (HS) code:: 85285210
