KVM extender Transmitter & receiver ADDER XD614P-DP Wired 4000m

Connectivity technology: The technology that enables connectivity of the device, e.g. wired or wireless.

Wired

PC Audio in: The socket (port) for the PC audio input.

Yes

Receiver depth:

148 mm

Receiver height:

39 mm

Receiver width:

186 mm

Maximum digital resolution:

1920 x 1200

PC Audio out:

Yes

RJ-45 ports quantity (receiver):

1

RJ-45 ports quantity (transmitter):

1

Transmitter local keyboard/mouse port type:

USB

Transmitter video port type:

DisplayPort

Receiver local video port type:

DisplayPort

Logistics data

Harmonized System (HS) code:

84733080

Other features

Supported resolutions:

4 heads at resolutions to a maximum of 1920x1200 60Hz

Weight & dimensions

Transmitter depth:

148 mm

Transmitter height:

39 mm

Transmitter width:

186 mm

Receiver weight:

1240 g

Transmitter weight:

1290 g

Technical details

Maximum transfer distance: The greatest distance over which the data/signal can be transferred.

4000 m

Type: Characteristics of the device.

Transmitter & receiver

USB 2.0 ports quantity: Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.

6

Material: The material from which a thing is or can be made e.g. wood, plastic.

Metal

Operational conditions

Operating relative humidity (H-H):

0 - 80

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-10 - 50

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 40

Packaging content

AC adapter included:

Yes

Video

Colour depth:

8 bit

Certificates

Certification:

CE, FCC

Ports & interfaces

RJ-11 ports quantity:

2

RJ-45 ports quantity:

2

Power

AC adapter output current:

12 A

AC input frequency:

47 - 63

AC input voltage: The voltage of the AC electricity that is inputted into the product.

100 - 240

Network

Cable types supported:

Fiber, Cat8.1, Cat7e, Cat7, Cat6e, Cat6a, Cat6+, Cat6

Features

Plug and Play: Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.

Yes

Product colour: The colour e.g. red, blue, green, black, white.

Black
