APC EasyPDU, Switched, Zero U, 22 kW, 230V, (18) C13 & (6) C19；IEC309

Operating altitude:

0 - 3000

Operating relative humidity (H-H):

5 - 95

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-25 - 65

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

-5 - 50

Storage relative humidity (H-H):

5 - 95

Output voltage:

230

Nominal output voltage: The voltage which the manufacturer states that the device can produce.

230

Nominal input voltage: The voltage which the manufacturer recommends that the device needs to operate normally.

400

Mounting: What size the mounting head of the product is, to couple it with a camera.

Vertical

AC outlets quantity: The number of sockets in the device where AC electrical power can be connected.

24 AC outlet(s)

Maximum current: The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.

32 A

Rack capacity: The spase that device fill in rack.

0U

Load capacity:

22080 VA

Power plug: A power plug is a 2 or 3 pinned device that is placed into an electrical socket in order to make an electrical connection.

C13 coupler

Number of phases:

3

AC outlet types: The type of outlet for AC electricity.

C19 coupler, C13 coupler

PDU types: A power distribution unit (PDU) is a device fitted with multiple outputs designed to distribute electric power, especially to racks of computers and networking equipment located within the data center. PDUs vary from simple and inexpensive rack-mounted "power strips" to larger floor-mounted PDUs with multiple functions including power filtering to improve power quality, intelligent load balancing, and remote monitoring and control by LAN or SNMP.

Switched

Total carbon footprint (kg of CO2e): The total mean carbon footprint value generated across various lifecycle stages (manufacturing, transportation / logistics, use and end of life) per unit (for one single product) i.e., measured in kilograms CO2e.

2155

Compliance certificates: Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

UKCA, CE

Power

AC input frequency:

50/60

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

7.75 kg

Package weight: Weight of the packaged product.

9250 g

Height: The measurement of the product from head to foot or from base to top.

1650 mm

Width: The measurement or extent of something from side to side.

56 mm

Depth: The distance from the front to the back of something.

62 mm

Package depth: The distance from the front to the back of the packaging.

1810 mm

Package height: The distance from the top to the bottom of the packaging.

1260 mm

Package width: The distance from one side of the packaging to the other.

170 mm

Design

Type: Characteristics of the device.

Three-phase

Product colour: The colour e.g. red, blue, green, black, white.

Black
