Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
200 kg
-
Certification:
-
IEC 62040-1-1, IEC 62040-2, OSHPD
-
Battery technology:
The type of battery in the device, e.g. nickel–cadmium (NiCd).
-
Sealed Lead Acid (VRLA)
-
Operating altitude:
-
0 - 1005.8
-
Operating relative humidity (H-H):
-
0 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-15 - 40
-
Package weight:
Weight of the packaged product.
-
200000 g
-
Form factor:
The shape or design of the product.
-
Tower
-
Compatibility:
The other products, software and hardware this product can be used with.
-
Schneider Electric's lithium ion battery solution
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Non-operating altitude:
-
0 - 3048
-
Height:
The measurement of the product from head to foot or from base to top.
-
1485 mm
-
Width:
The measurement or extent of something from side to side.
-
521 mm
-
Depth:
The distance from the front to the back of something.
-
847 mm
-
Audible alarm(s):
Alarms that make a sound when they are activated (set off).
-
Yes
-
Output power capacity:
The maximum power that the device can produce.
-
20 kVA
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
White
-
Noise level:
The amplitude level of the undesired background noise, usually measured in decibels (db).
-
55 dB
-
Input frequency:
The frequency (Hz) which is required to power the product.
-
40/70
-
Maximum current:
The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.
-
54 A
-
Package depth:
The distance from the front to the back of the packaging.
-
990 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
1680 mm
-
Package width:
The distance from one side of the packaging to the other.
-
640 mm
-
Battery voltage:
The voltage (V) of the battery.
-
480 V
-
Output power:
The power that the device can produce.
-
20000 W
-
Power protection features:
Features that protect the device against power problems e.g. overload.
-
Overload, Short circuit
-
Power factor:
-
0.99
-
Input current Total Harmonic Distortion (THD):
-
3 %
-
Output voltage Total Harmonic Distortion (THD):
-
3 %
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP20
-
AC outlet types:
The type of outlet for AC electricity.
-
Hard Wire 5-wire (3PH + N + G)
-
Crest factor:
-
2.5:1
-
Input operation voltage (max):
The maximum input voltage supported by the device.
-
480 V
-
Input operation voltage (min):
The minumum voltage needed by the device during operation.
-
384 V
-
Output operation voltage (min):
The minumum voltage produced by the device during operation.
-
340 V
-
Output operation voltage (max):
The maximum output voltage produced by the device.
-
460 V
-
Output frequency:
-
50/60
-
ECO mode:
-
Yes
-
Display type:
Type of display (screen) e.g. LCD.
-
LED
-
Number of input phases:
-
3
-
Number of output phases:
-
3
-
Waveform:
-
Sine
-
UPS topology:
The two main UPS topologies are Double-Conversion True Online and Standby / Eco. Many quality-based considerations are involved when choosing the the optimal UPS for the job, like how they are coping with voltage disturbances.
-
Double-conversion (Online)
-
Harmonized System (HS) code:
-
85078000
-
SmartSlot:
-
Yes
-
Sustainability certificates:
-
RoHS
