Short description

The ARCTIC BioniX P120 Red is a pressure-optimised 120 mm gaming fan featuring PWM PST technology. It operates at a rotational speed of 200 to 2100 RPM, providing an airflow of 114.79 m³/h with a noise level of just 0.45 sone. The fan is equipped with a Fluid Dynamic Bearing for enhanced durability and performance. With a sleek black and red design, it fits perfectly in any gaming setup. Dimensions: 120 x 120 x 27 mm, Voltage: 12 V.

Available at price 10.99 €: 2 pcs.

Total available for order: 20 pcs.

Warranty: 2 Years

SKU: 1925457

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

29.06.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.17 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

29.06.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ARCTIC BioniX P120 Red is a 120 mm fan optimised for high static pressure, designed for use on heatsinks and in situations with increased air resistance. It operates on a 12 V supply with a rotational speed range from 200 to 2100 RPM, delivering an airflow up to 114.79 m³/h while maintaining a low noise output of 0.45 sone. The fan uses a Fluid Dynamic Bearing and a newly developed motor with reduced coil temperature to improve durability. Dimensions are 120 x 120 x 27 mm and the product comes in a black and red finish.

Advantages

The redesigned fan blades and pressure-optimised profile provide effective cooling performance against restrictive airflow, making the BioniX P120 particularly suited for heatsinks and radiators. PWM Sharing Technology (PST) enables seamless, synchronous speed control across multiple fans via PWM. The Fluid Dynamic Bearing and the low-temperature motor increase operational life, supported by an extended 10-year warranty.

Suitable for

CPU and GPU heatsinks with restricted airflow
Radiator and liquid cooling setups requiring high static pressure
Gaming PC cases where coordinated PWM fan control is desired

Key specifications

Type: Fan
Fan diameter: 120 mm
Speed range: 200–2100 RPM (PWM)
Airflow: up to 114.79 m³/h
Noise level: 0.45 sone
Bearing: Fluid Dynamic Bearing
Voltage: 12 V
Dimensions: 120 x 120 x 27 mm
Colour: Red, Black
Weight: 0.14 kg

How to use

Install the BioniX P120 Red in the desired fan position on the heatsink, radiator or case using the mounting screws supplied with your cooling assembly. Connect the fan to a PWM-capable header on the motherboard or to a compatible fan controller to allow speed regulation across the 200–2100 RPM range. For synchronized control of multiple ARCTIC PST-compatible fans, connect them in parallel as described in the motherboard or fan hub instructions.

Usage recommendations

Place the fan so that airflow aligns with your system’s cooling plan (intake or exhaust). Use PWM headers for coordinated speed control and verify clearance around the fan blades before powering on. Regularly check for dust buildup and clean as needed to maintain static pressure performance.

Specifications

Type:: Fan
Fan diameter:: 120 mm
Weight:: 0.14 kg
Supported processor sockets:: Not supported
Product colour:: Red, Black

All features

Performance

Type:: Fan
Fan diameter:: 120 mm
Supported processor sockets:: Not supported
Rotational speed (min):: 200 RPM
Rotational speed (max):: 2100 RPM
Maximum airflow:: 67.56 cfm
Compatible processor series:: Not supported
Airflow:: 114.79 m³/h
Bearing type:: Fluid Dynamic Bearing (FDB)
Pulse-width modulation (PWM) support:: Yes
Noise level:: 0.45 sone
Suitable location:: Computer case

Design

Product colour:: Red, Black
Number of fans:: 1 fan(s)
Fan connector:: 4-pin + 4-pin
Number of fan blades:: 5

Weight & dimensions

Cable length:: 0.4 m
Weight:: 0.14 kg
Package weight:: 175 g
Height:: 27 mm
Width:: 120 mm
Depth:: 120 mm
Package depth:: 125 mm
Package height:: 34 mm
Package width:: 130 mm

Technical details

Compliance certificates:: RoHS

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.: 1.56 W
Rated current:: 0.13 A
Voltage:: 12

Packaging content

Package type:: Box
Number of screws:: 4
Screws included:: Yes

Other features

Country of origin:: China
Mounting hole pattern (W x D):: 105 x 105

Logistics data

Harmonized System (HS) code:: 84733080

Hide Show all

Instructions

mmo_62511387_1542027927_9953_31865.pdf

Description

Instructions

mmo_62511387_1542027927_9953_31865.pdf

Machine translation. Load original

Reasons to buy

Optimised for Static Pressure

During the development of the new BioniX P120, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the BioniX P120 is particularly suitable for use on heatsinks and radiators. Optimised for Static Pressure

More Efficient Technology

The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new BioniX P120 to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance. More Efficient Technology

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.
Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor. Maximum Quietness, Minimum Vibration

Extended Life Span

A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years. Extended Life Span

200 to 2100 RPM regulated via PWM PST

With a wide range of regulation and the PWM Sharing Technology (PST), the BioniX P120 fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed. 200 to 2100 RPM regulated via PWM PST

High Quality Bearing

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and
greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan. High Quality Bearing

Strong Cooling Performance

Numerous improvements, such as an updated engine technology and a newly developed fan design, have noticeably increased the performance of P-fans. In internal performance tests leveled to 28 dB (A), the new P-fans left many competitors behind. Strong Cooling Performance
