header-product Fan ARCTIC P14 PWM Pressure-optimised 140 mm
11.49 €

Fan ARCTIC P14 PWM Pressure-optimised 140 mm

Fan ARCTIC P14 PWM Pressure-optimised Photo 1
Fan ARCTIC P14 PWM Pressure-optimised Photo 2
Fan ARCTIC P14 PWM Pressure-optimised Photo 3
Fan ARCTIC P14 PWM Pressure-optimised Photo 4
Fan ARCTIC P14 PWM Pressure-optimised Photo 5
Fan ARCTIC P14 PWM Pressure-optimised Photo 1
Fan ARCTIC P14 PWM Pressure-optimised Photo 2
Fan ARCTIC P14 PWM Pressure-optimised Photo 3
Fan ARCTIC P14 PWM Pressure-optimised Photo 4
Fan ARCTIC P14 PWM Pressure-optimised Photo 5
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Fan ARCTIC P14 PWM Pressure-optimised 140 mm

{{email}}
You keep track of price changes

Fan ARCTIC P14 PWM Pressure-optimised 140 mm

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

The ARCTIC P14 PWM is a 140 mm fan designed for optimal airflow and pressure. With a rotational speed of 200 to 1700 RPM, it offers a maximum airflow of 123.76 m³/h and a noise level of just 0.3 sone. The fan features Fluid Dynamic Bearing for durability and operates at 12 V. Its dimensions are 140 mm x 140 mm x 27 mm, and it comes in a sleek white color, making it a great addition to any setup.
Available at price 11.49 €: 10 pcs.
Total available for order: 14 pcs.
Warranty: 2 Years
SKU: 3953826
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
02.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
07.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 0.21 kg)
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
07.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ARCTIC P14 PWM Pressure-optimised 140 mm is a 140 mm case/heatsink fan engineered for high static pressure and efficient airflow. It features redesigned fan blades and a newly developed motor with lower coil temperature for increased durability. The fan operates on 12 V with a wide, stepless PWM-controlled speed range from 200 to 1700 RPM, offering a maximum airflow of 123.76 m³/h while maintaining low noise levels (0.3 sone). Its Fluid Dynamic Bearing further enhances lifespan and reliability, and the unit measures 140 x 140 x 27 mm in a white finish.

Advantages

The pressure-optimised blade design improves performance on heatsinks and in restricted airflow environments, providing effective cooling where higher air resistance is present. The wide PWM speed range allows precise control from low to high RPM for balanced cooling and acoustic performance. The upgraded motor with reduced coil temperature and the Fluid Dynamic Bearing increase operational life, reflected in an extended 10-year warranty.

Suitable for

  • Cooling CPU heatsinks and radiators where high static pressure is required
  • PC cases with restricted airflow or dust filters
  • Systems needing quiet, controllable fans for mixed-load operation

Key specifications

  • Fan diameter: 140 mm
  • Dimensions: 140 x 140 x 27 mm
  • Voltage: 12 V
  • Speed (PWM): 200–1700 RPM
  • Maximum airflow: 123.76 m³/h
  • Noise level: 0.3 sone
  • Bearing type: Fluid Dynamic Bearing
  • Color: White
  • Weight: 0.194 kg
  • Brand / MPN / EAN: ARCTIC / ACFAN00222A / 4895213703093

How to use

Install the fan onto the case, radiator, or heatsink using the appropriate mounting holes and screws, ensuring correct airflow direction toward the component to be cooled. Connect the fan to a PWM-capable header on the motherboard or a compatible fan controller to enable stepless speed regulation between 200 and 1700 RPM. Verify secure power connection to the 12 V supply and avoid obstructing the blades during operation.

Usage recommendations

For optimal cooling on heatsinks and radiators, position the ARCTIC P14 PWM so that its pressure-optimised blades push air directly through fins or dense filters; use PWM control to balance noise and cooling according to workload, and maintain periodic cleaning to preserve airflow and prolong bearing life.

Specifications

Type:
Fan
Fan diameter:
140 mm
Weight:
0.194 kg
Supported processor sockets:
Not supported
Product colour:
White
All features

Performance

Type:
Fan
Fan diameter:
140 mm
Supported processor sockets:
Not supported
Rotational speed (min):
200 RPM
Rotational speed (max):
1700 RPM
Maximum airflow:
72.8 cfm
Compatible processor series:
Not supported
Airflow:
123.76 m³/h
Maximum air pressure:
2.4 mmH2O
Bearing type:
Fluid Dynamic Bearing (FDB)
Pulse-width modulation (PWM) support:
Yes
Noise level:
0.3 sone
Suitable location:
Computer case
Quantity per pack:
1 pc(s)

Design

Product colour:
White
Number of fans:
1 fan(s)
Fan connector:
4-pin
Number of fan blades:
5

Weight & dimensions

Cable length:
0.4 m
Weight:
0.194 kg
Package weight:
234 g
Height:
27 mm
Width:
140 mm
Depth:
140 mm
Package depth:
143 mm
Package height:
29 mm
Package width:
143 mm

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.
1.44 W
Rated current:
0.12 A
Voltage:
12
Starting voltage:
3.9 V

Packaging content

Package type:
Box
Number of screws:
4
Screws included:
Yes

Logistics data

Harmonized System (HS) code:
84733080

Description

Machine translation. Load original

Reasons to buy

Optimised for Static Pressure

During the development of the new P14 PWM, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P14 PWM is particularly suitable for use on heatsinks and radiators.Optimised for Static Pressure

More Efficient Technology

The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new P14 PWM to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance.More Efficient Technology

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5% of the vibration from commutation of a regular DC motor without filter. Consequently, there is no need for rubber spacers thanks to the steady and smooth torque of the new motor.Maximum Quietness, Minimum Vibration

Extended Life Span

A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years.Extended Life Span

200 to 1700 RPM regulated via PWM

Thanks to the 4-pin connector, the RPM can be regulated in a broad spectrum via PWM. In this way, noise is kept at a minimum while maximum cooling performance is guaranteed when needed.200 to 1700 RPM regulated via PWM

High Quality Bearing

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.High Quality Bearing

Two Way Installation

- Push warm air out of the case

- Pull cool air into your caseTwo Way Installation
