Fan P12 PWM PST A-RGB 0dB

Name: Fan Arctic P12 PWM PST ACFAN00258A
Brand: Arctic
SKU: 4367264
Price: 31.49 EUR
Availability: OutOfStock

Aquaphor

Filters you can trust. Pure water every day.

Fan Arctic P12 PWM PST A-RGB 0dB

Short description

The Arctic P12 PWM PST A-RGB 0dB is a 120 mm fan featuring a semi-passive mode for silent operation. It operates at a rotational speed of 0 to 2000 RPM, providing an airflow of 82.91 m³/h. With a fluid dynamic bearing for durability, this fan is designed for efficient cooling while maintaining a sleek white design with digital A-RGB lighting.

Warranty: 2 Years

SKU: 4367264

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Arctic P12 PWM PST A-RGB 0dB is a 120 mm case fan designed for efficient airflow and quiet operation. It features a semi-passive 0 dB mode that allows the fan to stop completely at low thermal loads, while PWM control provides automatic speed adjustment up to 2000 RPM when additional cooling is required. The fan includes digital A-RGB lighting in a white housing and uses a fluid dynamic bearing for extended durability and stable performance.

Advantages

The semi-passive 0 dB mode reduces noise during low-load operation by stopping the fan when cooling demand is minimal. PWM PST (Pulse Width Modulation with Power Sharing Technology) enables coordinated speed control across multiple fans from a single PWM signal. The fluid dynamic bearing lowers mechanical wear for a longer service life, and the compact 120 mm form factor fits standard case mounts. Digital A-RGB lighting provides customizable illumination while preserving a clean white aesthetic.

Suitable for

PC chassis air circulation in desktops and small form-factor builds
Systems requiring quiet idle operation with occasional high-performance cooling
Setups where synchronized PWM control of multiple fans is desired
Builds that combine white components with addressable RGB lighting

Key specifications

Fan diameter: 120 mm
Speed range: 0–2000 RPM (PWM-controlled)
Airflow: 82.91 m³/h
Bearing type: Fluid dynamic bearing
Operating mode: Semi-passive 0 dB capability
Colour: White housing with digital A-RGB lighting
Weight: 0.131 kg

How to use

Install the fan in a standard 120 mm mounting location in the case using the supplied screws or compatible fasteners. Connect the PWM power connector to a motherboard header capable of PWM control; to use synchronized PST control, chain the additional fans using their PST connectors and connect the primary fan to the motherboard PWM header. Connect the A-RGB cable to a compatible addressable RGB header or controller to manage lighting. Configure fan curves and lighting effects in the motherboard or controller software to match system cooling and aesthetic preferences.

Usage recommendations

Position fans to establish clear intake and exhaust airflow paths within the case; maintain unobstructed fan intakes and clean dust filters regularly. Use PWM fan curves to balance noise and cooling: allow the semi-passive 0 dB mode for quiet idle periods and permit higher RPM under load. Ensure A-RGB connections match the system controller voltage and pinout before powering the system.

Specifications

Type:: Fan
Fan diameter:: 120 mm
Weight:: 0.131 kg
Supported processor sockets:: Not supported
Product colour:: White

All features

Performance

Type:: Fan
Fan diameter:: 120 mm
Supported processor sockets:: Not supported
Rotational speed (min):: 0 RPM
Rotational speed (max):: 2000 RPM
Maximum airflow:: 48.8 cfm
Compatible processor series:: Not supported
Airflow:: 82.91 m³/h
Bearing type:: Fluid Dynamic Bearing (FDB)
Pulse-width modulation (PWM) support:: Yes
Operating temperature (T-T):: 0 - 40
Suitable location:: Computer case
Quantity per pack:: 3 pc(s)
Fan static pressure:: 1.85 mmH2O

Design

Product colour:: White
Material:: Plastic
Fan connector:: 4-pin + 4-pin
Illumination LED:: Yes
Number of LEDs:: 12

Weight & dimensions

Cable length:: 0.48 m
Weight:: 0.131 kg
Package weight:: 560 g
Height:: 25 mm
Width:: 120 mm
Depth:: 120 mm
Package depth:: 124 mm
Package height:: 30 mm
Package width:: 127 mm

Power

Voltage:: 12
Fan voltage:: 12 V
Fan current:: 0.11 A
Starting voltage:: 5 V
LED voltage:: 12 V

Packaging content

Package type:: Box
Mounting kit:: Yes
Screws included:: Yes

Other features

Country of origin:: China

Logistics data

Harmonized System (HS) code:: 84733080

Hide Show all

Instructions

mmo_95957049_1643996314_3305_14174.pdf

Description

Instructions

mmo_95957049_1643996314_3305_14174.pdf

Machine translation. Load original

Reasons to buy

Full A-RGB Control for Vivid System Lighting

Equipped with 12 addressable A-RGB LEDs, the Arctic P12 PWM PST A-RGB 0dB lets you create precise, synchronized lighting effects. The LEDs are compatible with common motherboard A-RGB headers and external controllers, so you can match the fan’s illumination with the rest of your build for a cohesive, high-impact look.

Semi‑Passive 0 dB Mode for Silent Idle Operation

Featuring a 0 dB zero‑RPM capability via PWM control, this fan can stop spinning during low load to deliver silent operation. When system demand rises, PWM increases speed automatically to restore maximum cooling performance.

Extremely Smooth and Low‑Vibration Performance

The specially developed ARCTIC motor and rubberised contact surfaces minimise bearing noise and reduce audible vibrations, ensuring whisper‑quiet operation even at low speeds.

Optimised for High Static Pressure Cooling

Designed with a focused airflow profile, the P12 delivers high static pressure for efficient heat dissipation through radiators, heatsinks and dust filters — ideal for tight or obstructed airflow setups.

Wide 0–2000 RPM Range with PWM Sharing Technology (PST)

The broad speed range and PWM Sharing Technology let you synchronise and control multiple fans for balanced cooling and minimized noise, achieving optimal airflow management across your system.

Durable High‑Quality Bearing for Long Life

A German-engineered alloy and lubricant bearing combination reduces friction and heat, lowering noise and extending the fan’s service life for reliable long‑term cooling performance.
