Fan ARCTIC P12 Max

Name: Fan ARCTIC P12 Max 12 ACFAN00293A
Brand: Arctic
SKU: 10807633
Price: 12.49 EUR
Availability: InStock

Hot Deals at AiO.lv

Hurry and order now – up to 50% off!

Fan ARCTIC P12 Max 12 cm 300-3300 RPM 0.6 sone

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The ARCTIC P12 Max is a 12 cm computer case fan with a speed range of 300 to 3300 RPM and a noise level of 0.6 sone. It offers an airflow of 137.69 m³/h and utilizes Fluid Dynamic Bearing technology for improved durability and performance.

Available for order: 2 pcs.

Warranty: 2 Years

SKU: 10807633

Learn more

Cheapest delivery:

Unisend LV

Pick-up points

Unisend LV

Cost

1.79 €

Deliver

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

10.08.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

13.08.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.18 kg)

Parcel couriers

Unisend LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts pakomāts / DPD Paku skapis / Omniva LV / Latvijas Pasts nodaļa

13.08.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.79 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ARCTIC P12 Max is a 120 mm case fan designed for PC cooling with a speed range of 300–3300 RPM and a rated noise level of 0.6 sone. It delivers an airflow of 137.69 m³/h and uses Fluid Dynamic Bearing technology to enhance durability and running stability. The fan is finished in white and is intended for use as a system or case fan to improve airflow in desktops and gaming rigs.

Advantages

The P12 Max combines a wide rotational speed range with relatively high airflow for its size, while Fluid Dynamic Bearing reduces friction and extends service life. Its compact 120 mm form factor and white color make it suitable for many standard PC cases, and the model balances performance and acoustic characteristics for varied cooling needs.

Suitable for

Case cooling for desktop PCs
Airflow improvement in gaming rigs
Replacement or upgrade of existing 120 mm fans

Key specifications

Type: Fan
Fan diameter: 120 mm
Speed: 300–3300 RPM
Airflow: 137.69 m³/h
Noise level: 0.6 sone
Bearing: Fluid Dynamic Bearing
Weight: 0.184 kg
Colour: White
MPN: ACFAN00293A
EAN: 4895213704267

How to use

Mount the ARCTIC P12 Max in a compatible 120 mm fan slot in your PC case, aligning the airflow direction as needed (usually indicated by arrows on the fan frame). Connect the fan to the appropriate motherboard header or fan controller, observing the supported power and control method. Ensure screws or mounting hardware are secured to minimize vibration and check that the fan airflow complements the case cooling layout.

Usage recommendations

For balanced cooling and noise, use the P12 Max as an intake or exhaust fan depending on your case layout, and control fan speed via motherboard PWM or a compatible controller to match system load. Periodically clean dust from the blades and bearings to maintain optimal performance.

Specifications

Type: Characteristics of the device.: Fan
Product colour: The colour e.g. red, blue, green, black, white.: White
Suitable location: Locations in which the product can be used.: Computer case

All features

Packaging content

Number of screws:: 4
Screws included:: Yes
Package type: The type of product package e.g. box.: Box

Weight & dimensions

Package weight: Weight of the packaged product.: 214 g
Package height: The distance from the top to the bottom of the packaging.: 30 mm
Package depth: The distance from the front to the back of the packaging.: 125 mm
Package width: The distance from one side of the packaging to the other.: 127 mm
Cable length: How long the cable is.: 0.4 m
Fan weight:: 184 g
Fan dimensions (W x D x H):: 120 x 120 x 25
Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.: 0.184 kg
Height: The measurement of the product from head to foot or from base to top.: 25 mm
Depth: The distance from the front to the back of something.: 120 mm
Width: The measurement or extent of something from side to side.: 120 mm

Power

Maximum current: The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.: 0.29 A
Fan voltage:: 12 V
Fan current:: 0.29 A
Starting voltage:: 3.9 V
Voltage:: 12

Design

Fan connector:: 4-pin
Number of fan blades:: 5
Number of fans: The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).: 1 fan(s)
Product colour: The colour e.g. red, blue, green, black, white.: White

Performance

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 40
Fan's mean time to failure (MTTF):: 500000 h
Fan speed (max):: 3300 RPM
Fan speed (min):: 200 RPM
Fan static pressure:: 4.35 mmH2O
Quantity per pack:: 1 pc(s)
Bearing type:: Fluid Dynamic Bearing (FDB)
Pulse-width modulation (PWM) support:: Yes
Maximum air pressure:: 4.35 mmH2O
Airflow:: 137.69 m³/h
Maximum airflow:: 81.04 cfm
Noise level:: 0.6 sone
Rotational speed (max):: 3300 RPM
Rotational speed (min):: 300 RPM
Compatible processor series: A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'.: Not supported
Supported processor sockets: The sockets (plugs) for processors that are supported (can be used) by the device.: Not supported
Fan diameter: The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan.: 120 mm
Type: Characteristics of the device.: Fan
Suitable location: Locations in which the product can be used.: Computer case

Hide Show all

Instructions

mmo_117324104_1706640006_8523_13008.pdf

arctic-cooling-ACFAN00293A-10807633.pdf

Description

Instructions

mmo_117324104_1706640006_8523_13008.pdf

arctic-cooling-ACFAN00293A-10807633.pdf

Machine translation. Load original

Reasons to buy

Virtually Silent due Fluid Dynamic Bearing

As a special feature, the white version of the P12 Max is equipped with ARCTIC's proven Hydrodynamic Bearing. This enables virtually silent operation at low speeds that customers have been asking for. At maximum speed, brute performance is still guaranteed. Although these bearings tend to wear out, ARCTIC does not compromise on durability and still offers the 6-year warranty.

Virtually Silent due Fluid Dynamic Bearing

Extremely Wide Speed Range

The P12 Max features a controllable speed across an impressively wide range from 200 rpm up to 3300 rpm. This enables quiet operation when low airflow is needed and also delivers an unprecedented level of performance on heatsinks and radiators. The P12 Max provides a significant performance boost to existing air and water cooling solutions.

Extremely Wide Speed Range

Maximum Performance - Without Compromises

The P12 Max delivers focused airflow and high static pressure, making it suitable for all scenarios. The fan is optimised for use on radiators, heat sinks, pinholes and mesh. Therefore, the P12 Max is the ideal fan for enthusiasts and professionals who are looking for maximum performance with a long service life.

Maximum Performance - Without Compromises

0dB Mode - Zero RPM

The fan speed can be throttled down to a standstill via PWM. This allows silent operation in IDLE while at the same time guaranteeing maximum performance when required. Thus, the P12 Max enables an incomparably dynamic adjustment of speed so the airflow can be perfectly regulated for every case.

0dB Mode - Zero RPM

Improved Stability

The P12 Max features a closed fan wheel design. The advantage of this fan wheel is uncompromised pressure stability. In scenarios with high pressure resistance and higher speeds, the force is distributed uniformly over the entire fan wheel, enabling low-vibration rotation while maintaining high static pressure.

Improved Stability

Maximum Smoothness, Minimum Vibration

Due to sinus magnetization, the new motor produces only about 5% of the vibration caused by commutation of a regular DC motor without filter. The rubber pads mounted at the corners additionally dampen residual vibrations caused by higher revolutions.

Maximum Smoothness, Minimum Vibration

{{product.title}} Show details Hide details

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the Fan ARCTIC P12 Max cost, and is it available for purchase?

The price is 12.49 € (valid at the time of publication and already includes all taxes). The item is available for order — 2 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 10.08.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Bank transfer, Bank cards on-line, Apple Pay, Google Pay. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All Arctic products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized Arctic service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: type, product colour, suitable location, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for Fan ARCTIC P12 Max?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
