Type:
Characteristics of the device.
-
Air cooler
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.415 kg
-
Package weight:
Weight of the packaged product.
-
618 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Height:
The measurement of the product from head to foot or from base to top.
-
136 mm
-
Width:
The measurement or extent of something from side to side.
-
108 mm
-
Depth:
The distance from the front to the back of something.
-
83 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Aluminium
-
Package depth:
The distance from the front to the back of the packaging.
-
171 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
110 mm
-
Package width:
The distance from one side of the packaging to the other.
-
131 mm
-
Package type:
The type of product package e.g. box.
-
Box
-
Number of fans:
The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).
-
2 fan(s)
-
Fan diameter:
The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan.
-
100 mm
-
Supported processor sockets:
The sockets (plugs) for processors that are supported (can be used) by the device.
-
LGA 1700
-
Suitable location:
Locations in which the product can be used.
-
Processor
-
Fan speed (max):
-
2300 RPM
-
Fan speed (min):
-
200 RPM
-
Fan voltage:
-
12 V
-
Fan current:
-
0.13 A
-
Fan connector:
-
4-pin
-
Heat pipes diameter:
-
6 mm
-
Number of heat pipes:
-
2
-
Thermal Design Power (TDP):
-
350 W
-
Fan dimensions (W x D x H):
-
100 x 100 x 25
-
Bearing type:
-
Fluid Dynamic Bearing (FDB)
-
Number of fins:
-
46
-
Pulse-width modulation (PWM) support:
-
Yes
-
Fins material:
-
Aluminium
