Wi-Fi standards:
-
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
-
Motherboard chipset:
-
Intel H770
-
Package weight:
-
1979 g
-
Processor manufacturer:
-
Intel
-
BIOS memory size:
-
192 Mbit
-
Bluetooth version:
-
5.2
-
Motherboard form factor:
-
ATX
-
Line-in:
-
Yes
-
Ethernet LAN:
-
Yes
-
Maximum internal memory:
-
128 GB
-
RAID levels:
-
1, 5, 10
-
Width:
-
305 mm
-
Depth:
-
244 mm
-
Maximum number of SMP processors:
-
1
-
Compatible processor series:
-
Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
-
BIOS type:
-
UEFI AMI
-
Cables included:
-
SATA
-
Bluetooth:
-
Yes
-
Audio output channels:
-
7.1
-
Ethernet LAN (RJ-45) ports:
-
1
-
Headphone outputs:
-
1
-
Microphone in:
-
Yes
-
S/PDIF out port:
-
Yes
-
Processor socket:
-
LGA 1700
-
USB 2.0 connectors:
-
2
-
CPU fan connector:
-
Yes
-
Number of COM connectors:
-
1
-
ATX Power connector (24-pin):
-
Yes
-
Chassis intrusion connector:
-
Yes
-
Number of chassis fan connectors:
-
4
-
Parallel processing technology support:
-
Not supported
-
Front panel audio connector:
-
Yes
-
Wi-Fi:
-
Yes
-
Number of HDDs supported:
-
4
-
WiFi-AP antenna jack:
-
2
-
Non-ECC:
-
Yes
-
HDMI ports quantity:
-
1
-
Package depth:
-
75 mm
-
Package height:
-
270 mm
-
Package width:
-
340 mm
-
HDMI version:
-
2.1
-
Cooling type:
-
Passive
-
DisplayPorts quantity:
-
1
-
Peripheral (Molex) power connectors (4-pin):
-
1
-
EPS power connector (8-pin):
-
Yes
-
RAID support:
-
Yes
-
Supported memory clock speeds:
-
7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400, 5200, 5000, 4800
-
Supported processor sockets:
-
LGA 1700
-
Supported memory types:
-
DDR5-SDRAM
-
Ethernet interface type:
-
2.5 Gigabit Ethernet
-
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
-
2
-
Memory channels:
-
Dual-channel
-
Number of SATA III connectors:
-
4
-
Unbuffered memory:
-
Yes
-
Windows operating systems supported:
-
Windows 10, Windows 11
-
Power source type:
-
ATX
-
User guide:
-
Yes
-
Motherboard chipset family:
-
Intel
-
Component for:
-
PC
-
Number of storage drives supported:
-
8
-
Memory slots type:
-
DIMM
-
DisplayPort version:
-
1.4
-
PCI Express x1 (Gen 3.x) slots:
-
2
-
Supported storage drive types:
-
HDD & SSD
-
Number of memory slots:
-
4
-
Supported storage drive interfaces:
-
M.2, SATA III
-
Number of M.2 (M) slots:
-
4
-
Thunderbolt headers:
-
1
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
-
4
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
-
2
-
Top Wi-Fi standard:
-
Wi-Fi 6 (802.11ax)
-
Front panel connector:
-
Yes
-
12V power connector:
-
Yes
-
RGB LED pin header:
-
Yes
-
USB 3.2 Gen 2x2 Type-C ports quantity:
-
1
-
PCI Express x16 (Gen 4.x) slots:
-
1
-
PCI Express x16 (Gen 5.x) slots:
-
1
-
Supported memory clock speed (max):
-
7200 MHz
