Dimensions (WxDxH):
Dimensions of the product (Width x Depth x Height).
-
117 x 98 x 26
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.21 kg
-
Certification:
-
EMC: EN 55032/35
EMI: CISPR 32, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV (Power Adapter), 1kV (Terminal Block); Signal: 1 kV
IEC 61000-4-6 CS: 150 kHz to 10 MHz: 3 V/m; 10 kHz to 30 MHz: 3 to 1 V/m; 30 kHz to 80 MHz: 1 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11 DIPs
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
0.975 W
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
TLS, 2048-bit RSA, 802.1x RADIUS
-
Safety:
List of regulatory safety standards for all countries in which this product has been certified.
-
UL 60950-1, UL 62368-1
-
Operating relative humidity (H-H):
-
5 - 95
-
Cabling technology:
Type of cable technology performance.
-
10/100Base-T(X)
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 75
-
Package weight:
Weight of the packaged product.
-
440 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 60
-
Serial interface type:
-
RS-232
-
Serial ports quantity:
The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces.
-
1
-
Storage relative humidity (H-H):
-
5 - 95
-
Output voltage:
-
9 - 48
-
LED indicators:
-
Status, Power, LAN
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3af
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
Taiwan
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
100, 10
-
Reset button:
-
Yes
-
Package height:
The distance from the top to the bottom of the packaging.
-
160 mm
-
Package width:
The distance from one side of the packaging to the other.
-
59 mm
-
Master (outer) case height:
-
178 mm
-
Master (outer) case width:
-
315 mm
-
Package length:
-
239 mm
-
Housing material:
What the casing of the product is made of.
-
Metal
-
RS-232 signals:
-
TXD, RXD, RTS, GND, DTR, DSR, DCD, CTS
-
Isolation:
-
1.5 kV
-
Baud rate:
-
921.6 Kbit/s
-
Data bits:
-
8, 7, 6, 5
-
Stop bits:
-
2, 1.5, 1
-
Parity bit:
-
Mark, Space, No, Even
-
Flow Control type:
-
XON/XOFF, RTS/CTS, DTR/DSR
-
Power source type:
What the power source is.
-
DC, PoE
-
User guide:
-
Yes
-
Power consumption (max):
The maximum amount of power used by the device.
-
1.22 W
-
Terminal block included:
-
Yes
-
Master (outer) case gross weight:
-
4972 g
-
Terminal block port:
-
Yes
-
Master (outer) case length:
-
490 mm
-
Products per master (outer) case:
-
10 pc(s)
-
Master (outer) case net weight:
-
3000 g
-
Master (outer) case volume:
-
27467.34 cm³
-
Package volume:
-
2265.35 cm³
-
DIN rail kit included:
-
Yes
-
Number of foot pads:
-
4 pc(s)
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS
