Type:
Characteristics of the device.
-
AV receiver
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.47 kg
-
Operating relative humidity (H-H):
-
0 - 80
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 60
-
Package weight:
Weight of the packaged product.
-
760 g
-
Material:
The material from which a thing is or can be made e.g. wood, plastic.
-
Metal
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Serial interface type:
-
RS-232
-
AC adapter included:
-
Yes
-
Serial ports quantity:
The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces.
-
1
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
No
-
Height:
The measurement of the product from head to foot or from base to top.
-
30 mm
-
Width:
The measurement or extent of something from side to side.
-
123 mm
-
Depth:
The distance from the front to the back of something.
-
140.2 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
4096 x 2160
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Impedance:
The effective resistance of an electric circuit or component to alternating current, arising from the combined effects of ohmic resistance and reactance.
-
100 Ω
-
DC-in jack:
The socket/plug where the DC electricity supply connects to the device.
-
Yes
-
Bandwidth:
-
10.2 Gbit/s
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
Taiwan
-
Package depth:
The distance from the front to the back of the packaging.
-
239 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
160 mm
-
Package width:
The distance from one side of the packaging to the other.
-
59 mm
-
Manual:
-
Yes
-
Firmware upgradeable:
-
Yes
-
Master (outer) case height:
-
175 mm
-
Master (outer) case width:
-
250 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
4096 x 2160, 1920 x 1080 (HD 1080), 3840 x 2160
-
Bandwidth:
Bandwidth is the difference between the upper and lower frequencies in a continuous set of frequencies. It is typically measured in Hertz (Hz). A key characteristic of bandwidth is that any band of a given width can carry the same amount of information, regardless of where that band is located in the frequency spectrum. For example, a 3 kHz band can carry a telephone conversation whether that band is at baseband (as in a POTS telephone line) or modulated to some higher frequency.
-
340 MHz
-
Operating voltage:
Defines the range of operating voltages available
-
5 V
-
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
-
Yes
-
Maximum refresh rate:
-
60 Hz
-
3D:
The device can be used with 3D technology.
-
Yes
-
Baud rate:
-
57.6 Kbit/s
-
Number of HDMI outputs:
Port (socket) for HDMI output.
-
2
-
Cable types supported:
-
Cat5e, Cat6, Cat6a
-
Maximum transfer distance:
The greatest distance over which the data/signal can be transferred.
-
150 m
-
Remote (IR) input:
-
1
-
Remote (IR) output:
-
1
-
RJ-45 input ports:
-
1
-
HDCP version:
-
2.2
-
Master (outer) case gross weight:
-
4150 g
-
Consumer Electronics Control (CEC) support:
-
Yes
-
Master (outer) case length:
-
325 mm
-
Master (outer) case net weight:
-
3050 g
-
Master (outer) case volume:
-
14158.42 cm³
-
Package volume:
-
2265.35 cm³
-
HDBaseT port:
-
Yes
-
Infrared (IR) frequency range:
-
30 - 56
