Short description

The ATEN 4 x 2 True 4K Presentation Matrix Switch (VP1421) supports a maximum resolution of 4096 x 2160 pixels. It features a durable metal housing in black, with intuitive button and rotary control types. With a typical power consumption of 14.93 W, it is efficient for various setups. The compact design (170.1 mm width, 200 mm depth, 44 mm height) makes it suitable for different environments. Ideal for presentations and video conferencing.
Available at price 1,045.49 €: 2 pcs.
Total available for order: 4 pcs.
Warranty: 2 Years
SKU: 3097332
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
09.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
14.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 2.19 kg)
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
14.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
0 credit

pay in 3 equal parts

today

0 €

afterward

3 mth. х 348.5 €

overpayment

0 €

All payment Methods:
Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment, Leasing for legal entities
36 months installment: from 29.04 euros per month
Leasing for legal entities: from 36.38 euros per month
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The ATEN VP1421 is a compact multi-in-one presentation switch that combines a video matrix, True 4K scaler, HDBaseT extender, audio DSP and analog-to-digital conversion in a single metal enclosure. Designed for meeting rooms and educational spaces, the VP1421 supports resolutions up to 4096 x 2160 @ 60Hz (4:4:4) with HDR and provides flexible input and output options for presentations and video conferencing.

Advantages

The VP1421 delivers True 4K HDR visual clarity and simultaneous scaling to 4K and 1080p, enabling sharp, accurate images across displays. It supports up to four inputs (1 HDBaseT, 2 HDMI, 1 VGA) with smooth source switching and built-in HDBaseT transmission over a single Cat6/Cat6a cable up to 140 m, carrying AV, power and bi-directional RS-232/IR control. An onboard audio DSP provides microphone support with selectable 48V phantom power, automatic program-audio ducking for clearer speech, and flexible embedding/de-embedding to HDMI, line out and optical outputs. Multiple control options — front-panel buttons, IR remote, web GUI, RS-232, Ethernet and contact closure — simplify integration and operation.

Suitable for

  • Corporate meeting rooms and boardrooms
  • Lecture halls and classrooms
  • Small-to-medium conference spaces and training rooms
  • Video conferencing systems requiring multiple inputs and flexible audio routing

Key specifications

  • Model: ATEN VP1421
  • Max resolution: 4096 x 2160 @ 60Hz (4:4:4), HDR support
  • Inputs: 1 x HDBaseT, 2 x HDMI, 1 x VGA
  • Outputs: HDMI and HDBaseT (supports simultaneous scaled outputs)
  • HDBaseT range: up to 140 m over Cat6/Cat6a or ATEN 2L-2910 Cat6 cable (with both HDBaseT input and output)
  • Audio: built-in DSP, mic input with selectable 48V phantom power, audio embedding and de-embedding (HDMI, Line Out, Optical)
  • Control: front-panel buttons, IR remote, web-based GUI, RS-232, Ethernet, Contact Closure
  • Construction: metal housing, compact dimensions (170.1 x 200 x 44 mm), weight 1.58 kg
  • Power consumption: typical 14.93 W
  • MPN/EAN: VP1421 / 4719264649158

How to use

Connect source devices to the available inputs (HDBaseT, HDMI, VGA), connect displays to the HDMI and/or HDBaseT outputs and, if needed, run a Cat6/Cat6a cable to extend AV and control up to 140 m. Configure scaling, audio embedding and routing via the front-panel controls, the web-based GUI or an external control system using RS-232 or Ethernet. When using a microphone, enable the 48V phantom power if required and adjust the audio DSP settings to mix mic and program audio and apply automatic ducking for speech intelligibility.

Usage recommendations

For optimal HDBaseT performance use high-quality Cat6 or Cat6a cables (ATEN recommends 2L-2910 Cat6 for best results), ensure firmware is up to date, and verify display EDID settings when mixing 4K and 1080p outputs to avoid resolution or color-space mismatches.

Specifications

Weight:
1.58 kg
All features
Built-in display:
No
Housing colour:
Black
HDMI input ports quantity:
2
HDMI output ports quantity:
1

Ports & interfaces

Ethernet LAN (RJ-45) ports:
1
DC-in jack:
Yes
Remote (IR) input:
1
Remote (IR) output:
1
RJ-45 input ports:
1
RJ-45 output ports:
1
VGA (D-Sub) input ports:
1

Technical details

Control type:
Buttons, Rotary
On/off switch:
Yes
Product type:
Scaling matrix switcher

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.
14.93 W

Weight & dimensions

Weight:
1.58 kg
Height:
44 mm
Width:
170.1 mm
Depth:
200 mm

Operational conditions

Operating relative humidity (H-H):
0 - 80
Storage temperature (T-T):
-20 - 60
Operating temperature (T-T):
0 - 40
Storage relative humidity (H-H):
0 - 80

Packaging data

Package weight:
2200 g
Package depth:
414 mm
Package height:
117 mm
Package width:
207 mm

Packaging content

AC adapter included:
Yes
Manual:
Yes
IR receiver included:
Yes

Logistics data

Master (outer) case height:
232 mm
Master (outer) case width:
370 mm
Master (outer) case gross weight:
7250 g
Master (outer) case length:
427 mm
Products per master (outer) case:
3 pc(s)
Master (outer) case net weight:
4740 g
Harmonized System (HS) code:
85299097

Features

Maximum resolution:
4096 x 2160
Remote control included:
Yes
Heat dissipation:
110 BTU/h
Housing material:
Metal
HDCP:
Yes
3D:
Yes
HDCP version:
2.2
Extended display identification data (EDID):
Yes
High Dynamic Range (HDR) supported:
Yes
