Digital zoom:
-
1 x
-
Megapixel (approx.):
-
8 MP
-
Optical zoom:
-
30 x
-
Weight:
-
2 kg
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
19 W
-
Zoom capability:
-
Yes
-
Supported network protocols:
-
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
-
White balance:
-
ATW, Auto, Manual, One push
-
Operating relative humidity (H-H):
-
20 - 80
-
Products per pallet:
-
72 pc(s)
-
Storage temperature (T-T):
-
-20 - 60
-
Package weight:
-
4900 g
-
Operating temperature (T-T):
-
0 - 40
-
AC adapter included:
-
Yes
-
Line-in:
-
Yes
-
Cable lock slot:
-
Yes
-
Storage relative humidity (H-H):
-
20 - 95
-
Height:
-
192 mm
-
Focal length range:
-
4.5 - 135
-
Sensor type:
-
Exmor
-
Image stabilizer:
-
Yes
-
Minimum illumination:
-
0.46 lx
-
Focus adjustment:
-
Auto/Manual
-
Optical sensor size:
-
25.4 / 2.8
-
Width:
-
180 mm
-
Depth:
-
145 mm
-
Remote control included:
-
Yes
-
Product colour:
-
Black
-
Cables included:
-
RS-232
-
Tilt angle range:
-
-30 - 90
-
Ethernet LAN (RJ-45) ports:
-
1
-
DC-in jack:
-
Yes
-
Pan range:
-
-170 - 170
-
Cable management:
-
Yes
-
Progressive scan:
-
Yes
-
Snapshot:
-
Yes
-
Country of origin:
-
Taiwan
-
Input current:
-
2
-
Remote control type:
-
IR
-
RS-232 ports:
-
1
-
HDMI ports quantity:
-
1
-
Web-based management:
-
Yes
-
Ethernet LAN data rates:
-
10, 100, 1000
-
Package depth:
-
245 mm
-
Package height:
-
303 mm
-
Package width:
-
292 mm
-
Warranty card:
-
Yes
-
Package type:
-
Box
-
Supported video modes:
-
720p, 1080p, 2160p
-
Photo feature:
-
Yes
-
Audio codecs:
-
AAC-LC
-
Mounting type:
-
Stand/Wall mounting
-
Combined zoom:
-
30 x
-
Face tracking:
-
Yes
-
Video formats supported:
-
M-JPEG, YUY2
-
Maximum video resolution:
-
3840 x 2160
-
Maximum frame rate:
-
60 fps
-
PTZ control:
-
Yes
-
RS-422 ports:
-
1
-
Windows operating systems supported:
-
Y
-
Mac operating systems supported:
-
Y
-
Other operating systems supported:
-
iOS
-
Power source type:
-
DC
-
Camera type:
-
Single camera
-
Back Light Compensation (BLC):
-
Yes
-
Mounting kit:
-
Yes
-
AC input frequency:
-
50/60
-
AC input voltage:
-
100-240
-
Number of TV lines:
-
1400
-
Auto-tracking:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Mounting brackets included:
-
Yes
-
DC input voltage:
-
12
-
Streaming capability:
-
Yes
-
Power supply included:
-
Yes
-
Network streaming:
-
Yes
-
Number of screws:
-
8
-
Screws included:
-
Yes
-
HD type:
-
4K Ultra HD
-
Screen mirroring:
-
Yes
-
Cable lock slot type:
-
Kensington
-
Audio channels:
-
2
-
Remote control function:
-
Yes
-
Flip & mirror:
-
Yes
-
Products per master (outer) case:
-
1 pc(s)
-
Harmonized System (HS) code:
-
8525890000
-
Horizontal field of view (wide):
-
62.3 °
-
Horizontal field of view (tele):
-
2.5 °
-
Tilt speed (min):
-
0.1 °/sec
-
Tilt speed (max):
-
100 °/sec
-
Pan speed (min):
-
0.1 °/sec
-
Pan speed (max):
-
100 °/sec
-
Gain control type:
-
Auto/Manual
-
Number of camera presets:
-
10
-
3D NR (Noise Reduction):
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR), Variable Bit Rate (VBR)
-
Pan preset speed:
-
200 °/sec
-
Tilt preset speed:
-
200 °/sec
-
PTZ protocols:
-
PELCO-P/D, VISCA
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity:
-
1
-
Number of cable ties:
-
4
-
Cable ties included:
-
Yes
-
3G-SDI output:
-
Yes
-
Vertical field of view (tele):
-
1.4 °
-
Vertical field of view (wide):
-
37.3 °
-
Field of view (wide):
-
69.2 °
-
Field of view (tele):
-
2.8 °
-
Multi-stream capability:
-
5: HDMI / RTSP / NDI HX2 / USB(4Kp60) & 3G-SDI(1080P60) or 4: HDMI / RTSP / NDI HX3(4Kp60) & 3G-SDI(1080P60)
-
Bit rate range:
-
512 - 12000
-
Tally light:
-
Yes
-
Network configuration:
-
DHCP, IP Address Gateway, Subnet Mask, DNS
-
Auto framing:
-
Yes
-
Warranty period:
-
2 year(s)
