PCIe Adapter Axagon PCEA-PSN

Name: PCIe Adapter Axagon PCEA-PSN with PCEA-PSN
Brand: AXAGON
SKU: 3603837
Price: 16.99 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

PCIe Adapter Axagon PCEA-PSN with 1 Parallel + 2 Serial Ports

Fast shipping

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The Axagon PCEA-PSN PCIe Adapter features 1 parallel and 2 serial ports, using ASIX AX99100 interface. It supports PCIe host interface with a maximum data transfer rate of 5 Gbit/s. This adapter is ideal for connecting legacy devices, ensuring compatibility and reliability. It is CE certified and made in China, with a compact package size of 145mm x 110mm.

Available at price 16.99 €: 2 pcs.

Total available for order: 60 pcs.

Warranty: 2 Years

SKU: 3603837

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

Tuesday {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

Tuesday {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

Friday {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.13 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

Friday {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The AXAGON PCEA-PSN PCI-Express card adds one parallel DB25 port on the board and two RS-232 serial DB9 ports on the bracket to a desktop PC. The card uses the ASIX AX99100 chipset and is compatible with PCI-Express x1 slots and larger, supporting PCIe 2.0 (backward compatible with 1.0a/1.1 and upward to 3.0). Low-profile brackets are included for installation in standard and small form-factor cases.

Advantages

The card provides both a parallel IEEE 1284 interface for printers and legacy devices and two high-speed RS-232 serial ports for POS, industrial and communication equipment. It features robust driver compatibility, hardware flow control options, extensive signal support (TXD, RXD, RTS, CTS, DTR, DCD, DSR, RI), and strong ESD protection. Plug-and-Play operation and included low-profile brackets simplify installation in a variety of PC builds.

Key specifications

Interface: PCI-Express 2.0 compatible with PCIe 1.0a/1.1/2.1/3.0, x1 lane (works in x1/x4/x8/x16 slots)
PCIe bandwidth: 5 Gb/s (1-lane PCIe 2.0)
Parallel port: 1× IEEE 1284 DB25 female on card (SPP/BYTE/ECP compatible)
Serial ports: 2× RS-232 DB9 male on bracket, connected via cable to card
UART compatibility: 16C550 / Extended 16C550 / 16C950
Driver throughput: RS-232 drivers guaranteed up to 250 kBd
FIFO: 256-byte transmit and receive buffer per port
Baud rate and data format: configurable baud rate, word length (5–9 bits), parity (even/odd/none/mark/space), stop bits (1/1.5/2)
Flow control: Xon/Xoff, hardware or none
Signals supported: TXD, RXD, RTS, CTS, DTR, DCD, DSR, RI
ESD protection: >±15 kV air, ±8 kV contact on serial ports
Chipset: ASIX AX99100
OS support: Windows XP, Vista, 7, 8, 8.1, 10 and later; Windows Server 2003/2008/2012/2016 and later (32/64-bit); Linux kernel 2.6.11 and above
Package contents: PCIe card with standard bracket, serial ports bracket, low-profile brackets, multilingual manual, cardboard box

How to use

Power off the PC and insert the card into a free PCI-Express x1 (or larger) slot. Choose and attach the appropriate bracket (standard or low profile) and secure it in the case. Connect the bracket cable to the card if the serial ports are on the separate bracket. Power on the PC; the device uses Plug and Play to assign IRQ and I/O addresses. Install drivers if required by the operating system. Configure baud rate, parity, flow control and COM port numbers in your OS or application as needed for the connected parallel or serial devices.

Recommendations

Use shielded cables and ensure proper grounding when connecting industrial equipment. Verify driver availability for your operating system version and configure COM port settings to match the requirements of connected printers, POS systems, CNC machines or other legacy devices.

Specifications

Host interface:: PCIe
Internal:: Yes
Output interface:: RS-232, Parallel

All features

Technical details

Compliance certificates:: RoHS

Ports & interfaces

Serial interface type:: RS-232, DB9
Parallel ports quantity:: 1
Serial ports quantity:: 2
Host interface:: PCIe
Output interface:: RS-232, Parallel
Expansion card standard:: PCIe 2.0
Expansion card form factor:: Full-height / Low-profile

Other features

Manual:: Yes

Weight & dimensions

Package weight:: 127 g

System requirements

Windows operating systems supported:: Y
Linux operating systems supported:: Y
Server operating systems supported:: Y

Design

Internal:: Yes

Performance

Certification:: CE

Logistics data

Country of origin:: China
Quantity per pack:: 1 pc(s)

Features

Plug and Play:: Yes
Data transfer rate (max):: 5 Gbit/s

Packaging data

Package depth:: 110 mm
Package height:: 25 mm
Package width:: 145 mm
Package type:: Box
