Grounding Angle Axing QEW 6-50 — grounding connector, model QEW00650

Axing Grounding Angle QEW 6-50 (model QEW00650) is a compact grounding connector designed to provide a reliable earthing point for cable and antenna installations in communication and broadcast systems. The angled body allows installation in confined spaces while maintaining a secure electrical connection between coaxial cable shields and the grounding conductor.

Advantages

The QEW 6-50 grounding angle features a compact, right-angle design that simplifies placement in restricted areas and reduces mechanical strain on cables. It provides a stable conductive path to ground, supports standard 6–50 coax interfaces, and is manufactured to ensure consistent contact and corrosion resistance appropriate for indoor and sheltered outdoor installations.

Suitable for

• Grounding coaxial cables in antenna installations
• Earthing points for broadcast and communication equipment
• Use in confined or angled mounting locations

Key specifications

• Brand: Axing
• Model / MPN: QEW00650
• Product type: Grounding connector (grounding angle)
• Interfaces: for 6–50 coaxial cable systems
• EAN: 7611682006438

How to use

Mount the grounding angle at the chosen grounding point and connect the coaxial cable shield to the connector according to standard installation practices. Secure the grounding conductor to the designated terminal and ensure tight mechanical and electrical connections. Verify continuity to the main grounding bus or earth rod after installation.

Usage recommendations

Use appropriate corrosion protection and follow local grounding regulations. Inspect connections periodically and tighten fittings as needed to maintain a low-resistance path to earth.
