Type:
-
IP security camera
-
Certification:
-
EN 55032 A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMB-3(A), VCCI A, RCM AS/NZS CISPR 32 A, KC KN32 A, KC KN35
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1
EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78
NIST SP500-267
-
Audio system:
-
1-way
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
3.8 W
-
Security algorithms:
-
EAP-TLS
-
Flash memory:
-
512 MB
-
Supported network protocols:
-
IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP
-
Operating relative humidity (H-H):
-
10 - 85
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-40 - 65
-
Form factor:
-
Box
-
Built-in microphone:
-
Yes
-
Operating temperature (T-T):
-
-20 - 50
-
Camera shutter speed:
-
1/33500 - 2
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
-
46 mm
-
LED indicators:
-
Y
-
Focal length range:
-
3 - 10.5
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0.02 lx
-
Optical sensor size:
-
25.4 / 3
-
Width:
-
70 mm
-
Depth:
-
148 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
1920 x 1080
-
Product colour:
-
Black
-
Networking standards:
-
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
-
Voice codecs:
-
G.711, G.726, OPUS
-
Bluetooth:
-
No
-
Audio formats supported:
-
AAC-LC, ADPCM, LPCM, PCM
-
Video compression formats:
-
AVC, H.264, H.265, HEVC, M-JPEG
-
Ethernet LAN (RJ-45) ports:
-
1
-
Microphone in:
-
Yes
-
DC-in jack:
-
Yes
-
Languages support:
-
CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POL, POR, RUS
-
Progressive scan:
-
Yes
-
Wi-Fi:
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor
-
Frame rate:
-
30 fps
-
Manual:
-
Yes
-
Supported graphics resolutions:
-
160 x 90, 1920 x 1080 (HD 1080)
-
Supported video modes:
-
1080p
-
Housing material:
-
Polycarbonate (PC)
-
Night vision:
-
Yes
-
Password protection type:
-
User
-
Mounting type:
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
Audio detection:
-
Yes
-
IP address filtering:
-
Yes
-
DC output voltage:
-
8, 28
-
Number of languages:
-
12
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
Power source type:
-
DC, PoE
-
Total megapixels:
-
2 MP
-
Image quality adjustment:
-
Brightness, Colour depth, Contrast, Sharpness
-
Mounting kit:
-
Yes
-
Built-in HDD:
-
No
-
Audio input channels:
-
1
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
6.49 W
-
Sample rate:
-
48 kHz
-
Video streaming:
-
Yes
-
Password protection:
-
Yes
-
Number of lenses:
-
1
-
Power consumption (Power over Ethernet (PoE)):
-
6.49 W
-
Infrared (IR) cut-off filter:
-
Yes
-
PTZ modes:
-
Digital PTZ
-
Number of sensors:
-
1
-
Gain control type:
-
Auto
-
Bit rate control:
-
Variable Bit Rate (VBR)
-
Streaming method:
-
Multicast, Unicast
-
Video intelligence analytic:
-
Yes
-
Lens viewing angle, horizontal:
-
90
-
Lens viewing angle, vertical:
-
49
