Type:
-
IP security camera
-
Weight:
-
3 kg
-
Audio system:
-
2-way
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
10.8 W
-
Security algorithms:
-
256-bit AES-XTS, FIPS 140-2, HTTPS, SNMP
-
Zoom capability:
-
Yes
-
Flash memory:
-
8192 MB
-
Supported network protocols:
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-40 - 65
-
Focus:
-
Motorized
-
Form factor:
-
Dome
-
Audio system full duplex:
-
Yes
-
Operating temperature (T-T):
-
-40 - 50
-
Camera shutter speed:
-
1/19500 - 1
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
-
75 mm
-
LED indicators:
-
Activity
-
Focal length range:
-
3.18 - 7.42
-
Sensor type:
-
CMOS
-
Image stabilizer:
-
Yes
-
Minimum illumination:
-
0.1 lx
-
Optical sensor size:
-
25.4 / 2.78
-
Width:
-
141 mm
-
Depth:
-
220 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2592 x 1944
-
Product colour:
-
Black, White
-
Networking standards:
-
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
-
LED type:
-
IR
-
Maximum operating distance:
-
20 m
-
Audio output channels:
-
2.0
-
Audio formats supported:
-
RTSP
-
Video compression formats:
-
M-JPEG, MPEG, MPEG4
-
Ethernet LAN (RJ-45) ports:
-
1
-
Built-in speaker(s):
-
Yes
-
Languages support:
-
ARA, CHI (SIMPL), CHI (TR), CZE, DUT, ENG, FIN, FRE, GRE, ITA, JPN, KOR, POL, POR, RUS, SWE, THA, TUR, VIE
-
Progressive scan:
-
Yes
-
Quality of Service (QoS) support:
-
Yes
-
Placement supported:
-
Outdoor
-
Frame rate:
-
20 fps
-
Manual:
-
Yes
-
Supported graphics resolutions:
-
640 x 360, 640 x 480 (VGA), 2560 x 1440, 2592 x 1944
-
Memory card included:
-
Yes
-
Housing material:
-
Aluminium, Polycarbonate (PC)
-
Frequency range:
-
50 - 60
-
Night vision:
-
Yes
-
Number of illumination LEDs:
-
2
-
Mounting type:
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
Audio detection:
-
Yes
-
IP address filtering:
-
Yes
-
Remotely operated:
-
Yes
-
Video formats supported:
-
H.264, H.265
-
Number of languages:
-
19
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
RAM capacity:
-
4096 MB
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP66
-
Power source type:
-
PoE
-
Total megapixels:
-
5 MP
-
Image quality adjustment:
-
Brightness, Contrast, Mirror, Saturation, Sharpness
-
Mounting kit:
-
Yes
-
Night vision distance:
-
20
-
Audio input channels:
-
2.0
-
Video recording:
-
Yes
-
Built-in light:
-
Yes
-
HTTPS encryption:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Mounting brackets included:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
23.7 W
-
Motion sensor:
-
Yes
-
IK code:
-
IK10
-
Video streaming:
-
Yes
-
Password protection:
-
Yes
-
Number of lenses:
-
3
-
Preset points:
-
Yes
-
Privacy masking:
-
Yes
-
Text caption overlay:
-
Yes
-
Alert notification type:
-
E-mail
-
Privacy protection:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
Number of sensors:
-
1
-
Fixed focus:
-
Yes
-
Remote viewing:
-
Yes
-
Intelligent Video Surveillance (IVS) system features:
-
Human detection, Vehicle detection
-
Bit rate control:
-
Variable Bit Rate (VBR)
-
Streaming method:
-
Multicast
-
Noise reduction technology:
-
2D noise reduction, 3D noise reduction
-
Camera tilt control:
-
Yes
-
Video intelligence analytic:
-
Yes
-
Doesn't contain:
-
BFR, CFR, PVC
-
Number of simultaneous live view channels:
-
4 channels
-
Pixel counter:
-
Yes
-
Human and vehicle targets classification:
-
Yes
-
Digest authentication:
-
Yes
-
Camera pixel size:
-
2 µm
-
Lens viewing angle, horizontal:
-
360
-
Lens viewing angle, vertical:
-
71.5 - 30.0
-
Sensor type (panoramic camera):
-
CMOS
-
Signal-to-Noise Ratio (SNR) (panoramic camera):
-
55 dB
-
Warranty period:
-
5 year(s)
-
License plate recognition:
-
Yes
-
Horizontal field of view (thermal module):
-
360
-
Network access storage (NAS):
-
Yes
-
Compliance certificates:
-
BSMI, CE, Federal Communications Commission (FCC), ICES, KC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UL, VCCI, cUL
