Type:
Characteristics of the device.
-
IP security camera
-
Processor model:
The model number for the processor in a computer.
-
ARTPEC-8
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.975 kg
-
Audio system:
System used to play music or speech.
-
2-way
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
10.2 W
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
EAP-TLS, HTTPS, MSCHAPv2, PEAP, TLS
-
Zoom capability:
The amount that the camera lens can zoom.
-
Yes
-
Flash memory:
-
8192 MB
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 65
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 50
-
Camera shutter speed:
Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
-
1/16000
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
133 mm
-
Focal length range:
Measure of how strongly the system converges or diverges light. For an optical system in air, it is the distance over which initially collimated rays are brought to a focus. A system with a shorter focal length has greater optical power than one with a long focal length; that is, it bends the rays more strongly, bringing them to a focus in a shorter distance.For an optical system in air, the effective focal length (f and f′) gives the distance from the front and rear principal planes (H and H′) to the corresponding focal points (F and F′).
-
3.2 - 8.1
-
Signal-to-Noise Ratio (SNR):
This is the ratio of signal intensity to noise intensity.
-
55 dB
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Minimum illumination:
Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
-
0 lx
-
Auto focus:
Device focusing a camera or other piece of equipment automatically.
-
Yes
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 2.8
-
Width:
The measurement or extent of something from side to side.
-
208 mm
-
Depth:
The distance from the front to the back of something.
-
127 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
3840 x 2160
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Silver
-
LED type:
-
IR
-
Tilt angle range:
-
-75 - 75
-
Bluetooth:
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
-
No
-
Audio formats supported:
The audio formats which this device or software can read/use e.g. MP3, MP4.
-
AAC-LC, ADPCM, G.711, G.726, LPCM, PCM
-
Video compression formats:
-
H.264, H.265, M-JPEG
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Headphone outputs:
Number of sockets /ports where headphones are connected.
-
1
-
Microphone in:
The socket where a microphone is connected to the device.
-
Yes
-
Angle of rotation:
-
240 °
-
Noise reduction:
-
Yes
-
Closest focusing distance:
-
0.5 m
-
Pan range:
-
-110 - 110
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
No
-
Card reader integrated:
A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Indoor & outdoor
-
Frame rate:
-
30 fps
-
Housing material:
What the casing of the product is made of.
-
Aluminium, Plastic, Polycarbonate (PC)
-
Minimum aperture number:
The minimum size of the hole through which light enters a camera.
-
3.2
-
Maximum aperture number:
-
1.9
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Mounting type:
Type of mounting e.g. wall mounting.
-
Ceiling/Wall
-
Ethernet interface type:
-
Gigabit Ethernet
-
RAM capacity:
-
4096 MB
-
Built-in processor:
Whether or not a processor is built into the device.
-
Yes
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66, IP67
-
Power source type:
What the power source is.
-
PoE
-
Camera shutter type:
Indicates if the camera shutter is mechanical or electronic.
-
Electronic
-
Total megapixels:
A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
-
8 MP
-
Image quality adjustment:
-
Brightness, Contrast, Mirror, Saturation, Sharpness
-
Built-in HDD:
The product has a hard drive built into it.
-
No
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
The quantity of cameras that product can support.
-
1
-
Power consumption (max):
The maximum amount of power used by the device.
-
18.8 W
-
IK code:
-
IK10
-
Video streaming:
-
Yes
-
Number of lenses:
The number of lenses installed in the device.
-
2
-
Privacy protection:
-
Yes
-
Number of sensors:
-
2
-
Remote viewing:
-
Yes
-
Gain control type:
-
Auto
-
Detect distance (wide):
-
87.8 m
-
Detect distance (tele):
-
220.1 m
-
Observe distance (wide):
-
34.8 m
-
Observe distance (tele):
-
87.3 m
-
Recognize distance (wide):
-
17.6 m
-
Recognize distance (tele):
-
44 m
-
Identify distance (wide):
-
8.8 m
-
Identify distance (tele):
-
22 m
-
Noise reduction technology:
-
2D noise reduction, 3D noise reduction
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Sensor type (panoramic camera):
-
CMOS
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CE, EAC, Federal Communications Commission (FCC), KC, RCM, Trade Agreements Act (TAA), UKCA, UL, VCCI, cUL
