Internal memory:
-
2000 MB
-
Type:
-
IP security camera
-
Weight:
-
0.85 kg
-
Audio system:
-
2-way
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
3.4 W
-
Security algorithms:
-
256-bit AES-XTS, EAP-TLS, MSCHAPv2, PEAP
-
Flash memory:
-
8 MB
-
Supported network protocols:
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
-
-40 - 65
-
Form factor:
-
Dome
-
Audio system full duplex:
-
Yes
-
Operating temperature (T-T):
-
-40 - 50
-
Camera shutter speed:
-
1/37000 - 2
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
-
107 mm
-
LED indicators:
-
Y
-
Focal length range:
-
10.8 - 28.2
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0.02 lx
-
Auto focus:
-
Yes
-
Optical sensor size:
-
25.4 / 2.8
-
Width:
-
183 mm
-
Depth:
-
156 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
1920 x 1080
-
Product colour:
-
Black, White
-
Networking standards:
-
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af
-
LED type:
-
IR
-
Tilt angle range:
-
-50 - 80
-
Audio formats supported:
-
AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
-
Microphone in:
-
Yes
-
Angle of rotation:
-
190 °
-
Closest focusing distance:
-
3 m
-
Pan range:
-
-190 - 190
-
Progressive scan:
-
Yes
-
Quality of Service (QoS) support:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
60 fps
-
Manual:
-
Yes
-
Supported graphics resolutions:
-
1280 x 800, 1440 x 1080, 1920 x 1080 (HD 1080)
-
Housing material:
-
Plastic, Polycarbonate (PC)
-
Minimum aperture number:
-
1.7
-
Maximum aperture number:
-
1.76
-
Night vision:
-
Yes
-
Mounting type:
-
Ceiling/Wall
-
Audio detection:
-
Yes
-
Video formats supported:
-
AV1, AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP66
-
Power source type:
-
PoE
-
Total megapixels:
-
2 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Protection features:
-
Impact resistant, Vandal proof
-
Lens diameter:
-
29 mm
-
Night vision distance:
-
45
-
Auto-tracking:
-
Yes
-
Tour recording:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
10 W
-
Fog proof:
-
Yes
-
IK code:
-
IK10
-
Weatherproof:
-
Yes
-
Video streaming:
-
Yes
-
Terminal block port:
-
Yes
-
Number of lenses:
-
1
-
Flip & mirror:
-
Yes
-
Text caption overlay:
-
Yes
-
Privacy protection:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
Number of sensors:
-
1
-
Gain control type:
-
Auto
-
Detect distance (wide):
-
149 m
-
Detect distance (tele):
-
394 m
-
Observe distance (wide):
-
59 m
-
Observe distance (tele):
-
157 m
-
Recognize distance (wide):
-
30 m
-
Recognize distance (tele):
-
79 m
-
Identify distance (wide):
-
15 m
-
Identify distance (tele):
-
39 m
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Streaming method:
-
Multicast
-
Noise reduction technology:
-
2D noise reduction, 3D noise reduction
-
Camera pan control:
-
Yes
-
People counting function:
-
Yes
-
Camera tilt control:
-
Yes
-
Doesn't contain:
-
BFR, PVC
-
Human and vehicle targets classification:
-
Yes
-
Lens viewing angle, horizontal:
-
29
-
Lens viewing angle, vertical:
-
16.4
-
Signal-to-Noise Ratio (SNR) (panoramic camera):
-
55 dB
-
Compliance certificates:
-
CE, EAC, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), ICES, KC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UKCA, UL, VCCI, cUL
