Internal memory:
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
-
2000 MB
-
Type:
Characteristics of the device.
-
IP security camera
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.85 kg
-
Audio system:
System used to play music or speech.
-
2-way
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
3.4 W
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
256-bit AES-XTS, EAP-TLS, MSCHAPv2, PEAP
-
Flash memory:
-
8 MB
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
MicroSD (TransFlash), MicroSDHC, MicroSDXC
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 65
-
Form factor:
The shape or design of the product.
-
Dome
-
Audio system full duplex:
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-40 - 50
-
Camera shutter speed:
Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
-
1/37000 - 2
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
107 mm
-
LED indicators:
-
Y
-
Focal length range:
Measure of how strongly the system converges or diverges light. For an optical system in air, it is the distance over which initially collimated rays are brought to a focus. A system with a shorter focal length has greater optical power than one with a long focal length; that is, it bends the rays more strongly, bringing them to a focus in a shorter distance.For an optical system in air, the effective focal length (f and f′) gives the distance from the front and rear principal planes (H and H′) to the corresponding focal points (F and F′).
-
10.8 - 28.2
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Minimum illumination:
Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
-
0.02 lx
-
Auto focus:
Device focusing a camera or other piece of equipment automatically.
-
Yes
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 2.8
-
Width:
The measurement or extent of something from side to side.
-
183 mm
-
Depth:
The distance from the front to the back of something.
-
156 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
1920 x 1080
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, White
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af
-
LED type:
-
IR
-
Tilt angle range:
-
-50 - 80
-
Audio formats supported:
The audio formats which this device or software can read/use e.g. MP3, MP4.
-
AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
-
Microphone in:
The socket where a microphone is connected to the device.
-
Yes
-
Angle of rotation:
-
190 °
-
Closest focusing distance:
-
3 m
-
Pan range:
-
-190 - 190
-
Progressive scan:
Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
-
Yes
-
Quality of Service (QoS) support:
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Indoor & outdoor
-
Frame rate:
-
60 fps
-
Manual:
-
Yes
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
1280 x 800, 1440 x 1080, 1920 x 1080 (HD 1080)
-
Housing material:
What the casing of the product is made of.
-
Plastic, Polycarbonate (PC)
-
Minimum aperture number:
The minimum size of the hole through which light enters a camera.
-
1.7
-
Maximum aperture number:
-
1.76
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Mounting type:
Type of mounting e.g. wall mounting.
-
Ceiling/Wall
-
Audio detection:
-
Yes
-
Video formats supported:
The type of video formats that can be used by this device.
-
AV1, AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
-
Ethernet interface type:
-
Fast Ethernet
-
PTZ control:
-
Yes
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Power source type:
What the power source is.
-
PoE
-
Total megapixels:
A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
-
2 MP
-
Image quality adjustment:
-
Brightness, Contrast, Saturation, Sharpness
-
Protection features:
Physical effects from which the product is protected e.g. water resistant, crash proof.
-
Impact resistant, Vandal proof
-
Lens diameter:
The size of the lens, measured by drawing a straight line from one side to the other, going through the centre of the lens.
-
29 mm
-
Night vision distance:
-
45
-
Auto-tracking:
-
Yes
-
Tour recording:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
The quantity of cameras that product can support.
-
1
-
Power consumption (max):
The maximum amount of power used by the device.
-
10 W
-
Fog proof:
-
Yes
-
IK code:
-
IK10
-
Weatherproof:
-
Yes
-
Video streaming:
-
Yes
-
Terminal block port:
-
Yes
-
Number of lenses:
The number of lenses installed in the device.
-
1
-
Flip & mirror:
-
Yes
-
Text caption overlay:
-
Yes
-
Privacy protection:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
Number of sensors:
-
1
-
Gain control type:
-
Auto
-
Detect distance (wide):
-
149 m
-
Detect distance (tele):
-
394 m
-
Observe distance (wide):
-
59 m
-
Observe distance (tele):
-
157 m
-
Recognize distance (wide):
-
30 m
-
Recognize distance (tele):
-
79 m
-
Identify distance (wide):
-
15 m
-
Identify distance (tele):
-
39 m
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Streaming method:
-
Multicast
-
Noise reduction technology:
-
2D noise reduction, 3D noise reduction
-
Camera pan control:
-
Yes
-
People counting function:
-
Yes
-
Camera tilt control:
-
Yes
-
Doesn't contain:
-
BFR, PVC
-
Human and vehicle targets classification:
-
Yes
-
Lens viewing angle, horizontal:
-
29
-
Lens viewing angle, vertical:
-
16.4
-
Signal-to-Noise Ratio (SNR) (panoramic camera):
-
55 dB
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CE, EAC, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), ICES, KC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UKCA, UL, VCCI, cUL
