Internal memory:
-
4096 MB
-
Type:
-
IP security camera
-
Digital zoom:
-
12 x
-
Optical zoom:
-
31 x
-
Weight:
-
4.4 kg
-
Certification:
-
EMC
EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, CISPR 35, EAC, EN 50121-4
Australia/New Zealand: RCM AS/NZS CISPR 32 Class A
Canada: ICES-3(A)/NMB-3(A)
Japan: VCCI Class A
Korea: KS C 9835, KS C 9832 Class A
USA: FCC Part 15 Subpart B Class A
Railway: IEC 62236-4
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471 risk group 2, IEC 60825-1 Class 1
IEC/EN 62262 IK10, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA 250, Type 4X, NEMA TS 2 (2.2.7–2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 (Method B), ISO 12944-6 C5
NIST SP500-267
ETSI EN 303 645, BSI IT Security Label, FIPS 140
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
13.7 W
-
Security algorithms:
-
PEAP, MSCHAPv2, EAP-TLS, 256-bit AES-XTS
-
Zoom capability:
-
Yes
-
Flash memory:
-
8192 MB
-
Supported network protocols:
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
-
Operating relative humidity (H-H):
-
10 - 100
-
Compatible memory cards:
-
SDXC, SDHC, SD
-
Storage temperature (T-T):
-
-40 - 65
-
Form factor:
-
Dome
-
Operating temperature (T-T):
-
-50 - 55
-
Camera shutter speed:
-
1/111000 - 1/2
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
-
291 mm
-
Focal length range:
-
6.91 – 214.64
-
Sensor type:
-
CMOS
-
Minimum illumination:
-
0.008 lx
-
Auto focus:
-
Yes
-
Optical sensor size:
-
25.4 / 2
-
Width:
-
239 mm
-
Depth:
-
239 mm
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
1920 x 1080
-
Product colour:
-
White, Black
-
Networking standards:
-
IEEE 802.3bt, IEEE 802.1x, IEEE 802.1AE
-
LED type:
-
IR
-
Tilt angle range:
-
-20 - 90
-
Ethernet LAN (RJ-45) ports:
-
1
-
Pan range:
-
0 - 360
-
Pan speed:
-
550 °/sec
-
Tilt speed:
-
550 °/sec
-
Progressive scan:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
60 fps
-
Supported graphics resolutions:
-
320 x 180
-
Housing material:
-
Aluminium
-
Night vision:
-
Yes
-
Mounting type:
-
Ceiling
-
Video formats supported:
-
MPEG4, M-JPEG, HEVC, H.265, H.264, AVC
-
Ethernet interface type:
-
Gigabit Ethernet, Fast Ethernet
-
PTZ control:
-
Yes
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP66, IP67
-
Image quality adjustment:
-
Sharpness, Contrast, Brightness
-
Protection features:
-
Weather resistant, Impact resistant
-
Night vision distance:
-
300
-
Tour recording:
-
Yes
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
51 W
-
IK code:
-
IK10
-
Weatherproof:
-
Yes
-
Video streaming:
-
Yes
-
Number of lenses:
-
1
-
Preset points:
-
Yes
-
Text caption overlay:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
PTZ modes:
-
Preset point
-
Number of sensors:
-
1
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Doesn't contain:
-
PVC/BFR, CFR
-
Lens viewing angle, horizontal:
-
60.6
-
Lens viewing angle, vertical:
-
36.5
-
Signal-to-Noise Ratio (SNR) (panoramic camera):
-
55 dB
-
Zoom speed:
-
1
-
Compliance certificates:
-
REACH, RoHS
