Type:
Characteristics of the device.
-
Basic access control reader
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.258 kg
-
Certification:
-
EAL6+
-
Operating relative humidity (H-H):
-
10 - 100
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 65
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-40 - 65
-
Storage relative humidity (H-H):
-
5 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
121 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
12
-
LED indicators:
-
Y
-
Width:
The measurement or extent of something from side to side.
-
85 mm
-
Depth:
The distance from the front to the back of something.
-
27 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Bluetooth:
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
-
No
-
Keypad illumination:
-
Yes
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
No
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
No
-
Fingerprint reader:
A scanner used to identify a person's fingerprint for security purposes. After a sample is taken, access to a computer or other system is granted if the fingerprint matches the stored sample. A PIN may also be used with the fingerprint sample.
-
No
-
PC connected:
The device is or can be connected to a PC.
-
No
-
Keypad number of keys:
-
12
-
RS-485 ports:
-
1
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP65, IP66
-
Recommended usage:
What the product should be used for, and how it should be used (e.g. ambient temperature).
-
Outdoor
-
Keypad integrated:
-
Yes
-
Built-in display:
A display which is part of the product, so you do not need to attach another display.
-
No
-
Alarm input/output:
-
No
-
Access code reader:
Device that is able to read an access code, and therefore determine whether the person with the card should be given access to the physical place or computer system.
-
Yes
-
Access chip/card reader:
Device that is able to read an access chip/card (smart card), and therefore determine whether the person with the card should be given access to the physical place or computer system.
-
Yes
-
Access chip/card reader type:
-
Contactless
-
Vandal-proof:
Product is designed to be installed in a location (or device) and application where they may be subject to vandalism or tampering.
-
Yes
-
Authentication type:
Authentification means proving identity to gain access to sometheng. There are various types of authentification exist e.g. access card, password, biometric data.
-
Password, Access chip/card
-
IK code:
-
IK07
-
Front camera:
Camera at the front of the product.
-
No
-
Built-in relay:
-
No
-
RFID frequency:
-
13.56 MHz
-
DC current (max):
-
0.134 A
-
Tamper protection:
-
Yes
-
Waste Electrical and Electronic Equipment (WEEE) compliance:
-
Yes
-
Open Supervised Device Protocol (OSDP):
-
Yes
-
Doesn't contain:
-
Lead, Mercury, Cadmium
-
Warranty period:
-
5 year(s)
-
Authentication card type:
-
MIFARE Classic, MIFARE DESFire EV1, MIFARE DESFire EV2, MIFARE Plus
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS, CE, UL, Federal Communications Commission (FCC), ICES, Electromagnetic Compatibility (EMC), RCM
