B-Tech SYSTEM X Joining Plate Kit for BT8390 to BT8380 Mounting

The B-Tech SYSTEM X Joining Plate Kit is a professional-grade mounting accessory engineered to seamlessly integrate BT8390 components with BT8380 support systems. This kit serves as a critical structural link for creating robust video wall configurations, whether they are freestanding, mobile, or permanently bolted to a surface. Crafted from high-quality steel with a durable black finish, it provides the necessary stability and precision required for complex audiovisual display setups.

Advantages

This joining plate kit offers exceptional versatility for installers looking to expand or customize their display environments. By utilizing the included sliding nuts, users can easily adjust the positioning of rails and columns along the support structure to achieve the perfect alignment. The design simplifies the assembly process for both single and twin screen installations, ensuring a secure and professional finish. Its robust steel construction guarantees long-term reliability, making it an ideal choice for demanding commercial or public display applications.

Suitable for

• Freestanding video wall installations
• Mobile display stands
• Bolt-down video wall configurations
• Single and twin screen System X setups

When it may not be suitable

This kit is specifically engineered for the B-Tech System X range, specifically to interface BT8390 rails with BT8380 columns. It is not compatible with mounting systems from other manufacturers or non-System X B-Tech products. If your installation does not involve these specific components, this plate will not provide the necessary mechanical fit.

Key specifications

• Material: Steel
• Colour: Black
• Width: 140.8 mm
• Depth: 57 mm
• Height: 158 mm
• Quantity: 1 piece per pack
• Compatibility: BT8390 rails to BT8380 columns

How to use

To install the joining plate, align the plate with the BT8380 support column and secure it using the provided sliding nuts and countersunk screws. The sliding mechanism allows you to position the mounted rail at any desired point along the column length. For multi-row video wall installations, it is recommended to use the separately available row height spacer to ensure consistent spacing between rails without the need for manual measurement.

What to consider before purchase

• Verify that your existing mounting rails are from the BT8390 series.
• Ensure your support columns are from the BT8380 series.
• Consider purchasing the BT8390-SP row height spacer if you are installing multiple rows of screens.
• Check the total weight capacity of your support structure to ensure it meets your display requirements.

Usage recommendations: Always ensure that all mounting hardware is tightened securely to maintain structural integrity. For large-scale video wall installations, utilize the optional row height spacer to achieve precise alignment and reduce installation time.
