bleBox ampBox amplifier module

Name: Amplifier module bleBox ampBox — ampBox
Brand: bleBox
SKU: 2134312
Price: 21.49 EUR
Availability: InStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Amplifier module bleBox ampBox — DC 12–24 V input, max 480 W, IP20, resin housing, 40×48×19 mm

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

bleBox ampBox is a compact amplifier module with DC power input (12–24 V) and maximum output power of 480 W. Encased in a black resin housing with IP20 protection, it measures 40×48×19 mm and operates between −10 and 40 °C. Designed for low-voltage audio or control applications where a small, high-power DC-driven amplifier module is required.

Available for order: 14 pcs.

Warranty: 2 Years

SKU: 2134312

Manufacturer: bleBox

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

26.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

26.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

01.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 €

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

01.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

bleBox ampBox is a compact four-channel amplifier module for low-voltage LED and control applications. It accepts DC input from 12 to 24 V and supports a maximum output power of 480 W. Housed in a black resin enclosure with IP20 protection and measuring 40×48×19 mm, the ampBox is intended for indoor installations and operates over an ambient temperature range from −10 °C to 40 °C. The module is compatible with common LED strips and can be integrated with other bleBox controllers to extend load capacity while maintaining a single control point.

Advantages

The ampBox combines high output power and a small footprint, enabling significant LED loads to be driven from a DC supply while occupying minimal installation space. Its resin housing provides basic protection suitable for indoor environments and its universal compatibility makes it usable with most LED strip types. When paired with bleBox controllers such as LightBox or wLightBox, the ampBox allows centralized smartphone or tablet control of larger lighting installations without replacing existing controllers.

Suitable for

Expanding existing low-voltage LED systems to handle higher loads
Driving multiple LED strips from a single DC 12–24 V supply
Discrete installations where compact amplifier modules are required
Integration with bleBox smart controllers for centralized control

Key specifications

Input voltage: DC 12–24 V
Maximum output power: 480 W
Channels: four-channel amplifier configuration
Operating temperature range: −10 °C to 40 °C
Enclosure: black resin housing
Protection rating: IP20 (suitable for indoor use)
Dimensions: 40 × 48 × 19 mm

How to use

Connect the ampBox to a regulated DC power source within the 12–24 V range and wire the LED strips to the amplifier outputs according to the channel arrangement. Ensure that the total connected load does not exceed the module's maximum output power of 480 W. Mount the unit in a dry, ventilated indoor location consistent with its IP20 protection level and observe the specified operating temperature limits. For smart installations, connect the ampBox outputs to the lighting circuits controlled by a compatible bleBox controller to increase the load capacity available to that controller.

Usage recommendations

Use a properly rated DC power supply with adequate current capacity and short-circuit protection. Verify the combined power draw of connected LED strips before installation and distribute loads across the four channels to avoid overloading any single channel. Install the ampBox in a location protected from moisture and excessive heat, and follow standard low-voltage wiring and safety practices.
