Crimp Ring Terminal BLOW 43-019# insulated M10 stud, cable 4.3 mm

Insulated ring crimp terminal BLOW 43-019# is designed for reliable attachment to an M10 stud and for crimping onto cables with about 4.3 mm conductor diameter. The terminal combines an electrically conductive copper or tinned copper barrel with an insulating sleeve to provide safe electrical contact and mechanical fixation where a ring connection is required. It is intended for applications in automotive, industrial and electrical panel wiring that require a robust ring terminal for M10 studs.

Advantages

The insulated construction reduces the risk of accidental short circuits and provides strain relief at the crimp point. The ring design ensures solid mechanical connection on M10 studs and prevents accidental disconnection under vibration when properly installed. The terminal is compact and suited for use where space is limited while still allowing a clear and visible bolted connection for maintenance and inspection.

Suitable for

• Automotive battery and grounding connections using M10 studs
• Industrial machinery wiring where a secure stud-mounted ring terminal is required
• Electrical distribution panels and control cabinets with M10 bus or stud connections
• Outdoor or mobile equipment that needs insulated terminal connections

Key specifications

• Terminal type: insulated ring (eye) crimp terminal
• Stud compatibility: M10
• Recommended conductor diameter: approximately 4.3 mm
• Material (typical): conductive metal barrel (copper or tinned copper) with insulating sleeve
• Connection method: crimp
• Typical use environment: automotive, industrial, electrical panels

How to use

Strip the cable to expose the specified conductor length and insert the conductor fully into the terminal barrel. Use an appropriately sized crimping tool to apply a secure crimp according to the cable cross-section and terminal dimensions. After crimping, inspect the joint for a firm mechanical hold and proper insulation coverage. Mount the ring over the M10 stud and secure with the appropriate nut and washer, ensuring correct torque per application requirements.

Usage recommendations

Use a calibrated crimping tool matched to insulated ring terminals and verify electrical continuity after installation. Select the correct cable size to match the recommended conductor diameter of approximately 4.3 mm. For vibration-prone applications, use locking washers or torque-specified fasteners to maintain mechanical integrity.
