Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.177 kg
-
Products per pallet:
Quantity of a single product per pallet. If more than one product is packed per carton; this is the number of products (not number of cartons) per shipping pallet.
-
1800 pc(s)
-
Package weight:
Weight of the packaged product.
-
306 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 60
-
Height:
The measurement of the product from head to foot or from base to top.
-
79 mm
-
Width:
The measurement or extent of something from side to side.
-
142 mm
-
Quantity:
The number of products there are.
-
1
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Grey
-
Voltage Standing Wave Ratio (VSWR):
-
2.0 : 1 max.
-
Package depth:
The distance from the front to the back of the packaging.
-
86 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
57 mm
-
Package width:
The distance from one side of the packaging to the other.
-
148 mm
-
Power consumption:
-
230 mA
-
Output impedance:
-
75
-
Noise figure:
-
0.2 dB
-
Feedhorn diameter:
-
49 mm
-
RF connector type:
-
F
-
Low band input frequency range:
-
10.7 - 11.7
-
High band input frequency range:
-
11.7 - 12.75
-
High band output frequency range:
-
1100 - 2150
-
Low band output frequency range:
-
950 - 1950
-
Conversion gain range:
-
60 - 70
-
Local Oscillator (LO) phase noise (10 kHz):
-
-80 dBc/Hz
-
Low band LO frequency:
-
9.75 GHz
-
High band LO frequency:
-
10.6 GHz
-
Image rejection:
-
50 dBmW
-
Temperature drift (±):
-
2 MHz
-
Initial accuracy (±):
-
1 MHz
-
Gain ripple (±):
-
1 dB
-
Cross-polarization isolation:
-
22 dB
-
Compression point (1 dB):
-
0 dBmW
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CE, UKCA
