Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
1.789 kg
-
Rack mounting:
The type of mounting that can position devices in a shelving system (rack).
-
Yes
-
MAC address table:
The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
-
2048 entries
-
Operating relative humidity (H-H):
-
10 - 90
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Package weight:
Weight of the packaged product.
-
2337 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Storage relative humidity (H-H):
-
10 - 95
-
Power source:
What is providing power for the product e.g. mains electricity.
-
AC
-
Height:
The measurement of the product from head to foot or from base to top.
-
44 mm
-
LED indicators:
-
Link, Power, Speed, Status
-
Width:
The measurement or extent of something from side to side.
-
320 mm
-
Depth:
The distance from the front to the back of something.
-
207 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Switching capacity:
The data transfer capacity of the switch per second.
-
40 Gbit/s
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
-
Cables included:
-
AC
-
Flow control support:
-
Yes
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Store-and-forward:
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
290 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
85 mm
-
Package width:
The distance from one side of the packaging to the other.
-
370 mm
-
Quick start guide:
Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
-
Yes
-
Housing material:
What the casing of the product is made of.
-
Metal
-
VLAN support:
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.
-
Yes
-
10G support:
The product can use Oracle 10G, which is a database management system introduced in 2003.
-
No
-
Copper ethernet cabling technology:
-
10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X
-
Forwarding rate:
-
29.76 Mpps
-
Cable types supported:
-
Cat5e, Cat3, Cat5
-
AC input frequency:
-
50/60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
Power consumption (max):
The maximum amount of power used by the device.
-
200 W
-
Power supply included:
There is a power supply with this product.
-
Yes
-
Power over Ethernet plus (PoE+) ports quantity:
-
16
-
Installed SFP+ modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 10 Gbit/s. The "SFP+ ports quantity" is the number of ports for SFP+ connections in a device.
-
0
-
Installed SFP modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The "SFP ports quantity" is the number of ports for SFP connections in a device.
-
0
-
Basic switching RJ-45 Ethernet ports type:
The type/category of basic switching RJ-45 Ethernet ports (sockets).
-
Gigabit Ethernet (10/100/1000)
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
18
-
Total Power over Ethernet (PoE) budget:
-
200 W
-
Packet buffer memory:
-
0.375 MB
-
Rack mount kit:
-
Yes
-
Power over Ethernet (PoE) power per port:
-
30 W
-
SFP module slots quantity:
-
2
-
Power connector:
-
AC-in jack
