Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.2952 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
3.37 W
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
944277.78 h
-
MAC address table:
The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
-
2000 entries
-
Operating relative humidity (H-H):
-
10 - 90
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-10 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Storage relative humidity (H-H):
-
5 - 90
-
Power source:
What is providing power for the product e.g. mains electricity.
-
DC
-
Height:
The measurement of the product from head to foot or from base to top.
-
82 mm
-
LED indicators:
-
Activity, Link, Power
-
Width:
The measurement or extent of something from side to side.
-
145 mm
-
Depth:
The distance from the front to the back of something.
-
28 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Switching capacity:
The data transfer capacity of the switch per second.
-
20 Gbit/s
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3
-
Heat dissipation:
The heat generated by the power supply.
-
14.28 BTU/h
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Input current:
-
0.5
-
Number of queues:
-
8
-
Store-and-forward:
-
Yes
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
10, 100, 1000, 2500
-
Switch type:
What switch device has, managed or unmanaged.
-
Unmanaged
-
Gigabit Ethernet (copper) ports quantity:
-
5
-
Housing material:
What the casing of the product is made of.
-
Metal
-
Auto MDI/MDI-X:
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
-
Yes
-
10G support:
The product can use Oracle 10G, which is a database management system introduced in 2003.
-
No
-
Copper ethernet cabling technology:
-
10BASE-T, 100BASE-T, 1000BASE-T, 2500BASE-T
-
Forwarding rate:
-
14.88 Mpps
-
DC input voltage:
-
12
-
Installed SFP+ modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The enhanced small form-factor pluggable (SFP+) is an enhanced version of the SFP that supports data rates up to 10 Gbit/s. The "SFP+ ports quantity" is the number of ports for SFP+ connections in a device.
-
0
-
Installed SFP modules quantity:
An SFP ("small form-factor pluggable transceiver") is a transmitter/receiver which interfaces a network device motherboard (e.g. in a switch, router) to a fibre optic or copper network cable. The "SFP ports quantity" is the number of ports for SFP connections in a device.
-
0
-
Basic switching RJ-45 Ethernet ports type:
The type/category of basic switching RJ-45 Ethernet ports (sockets).
-
Gigabit Ethernet (10/100/1000)
-
Basic switching RJ-45 Ethernet ports quantity:
The number of basic switching RJ-45 Ethernet ports (sockets).
-
5
-
Packet buffer memory:
-
2 MB
-
MAC address auto-learning supported:
-
Yes
-
Fanless:
-
Yes
-
Sustainability compliance:
-
Yes
-
2.5G Ethernet (copper) ports quantity:
-
2
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
BSMI, CE, Low Voltage Directive (LVD), RoHS
