Datalogic M34/STD/STD/N/N/N/UK/PC DSUB industrial barcode scanner module M3410-010200-03104

Datalogic M34/STD/STD/N/N/N/UK/PC DSUB is an industrial barcode scanner module, model M3410-010200-03104, designed for integration into equipment and OEM applications. Supplied as a DSUB-interface module, this compact scanning unit is intended for mounting inside automated systems, kiosks, or point-of-service devices where reliable barcode reading is required. The module supports integration via a DSUB connector and is tailored to environments that demand a small footprint, easy mechanical mounting, and direct electrical interfacing with host electronics.

Advantages

The module provides a compact form factor and a DSUB interface that simplifies electrical connection to host systems. It is built for industrial usage, offering stable barcode reading performance when embedded in machinery or terminals. Its design supports OEM integration, reducing the need for additional housings or adapters and enabling consistent placement of the scanning window within custom equipment. The module is suitable for continuous operation in automated workflows and can help streamline system assembly and maintenance.

Suitable for

• Integration into kiosks, terminals, and point-of-service devices
• OEM products where space is limited and a mountable scanner is required
• Automated inspection and scanning stations within production lines
• Embedded systems that require a direct DSUB interface for barcode data

Key specifications

• Form factor: compact, mountable scanner module
• Interface: DSUB connection for direct host integration
• Intended use: industrial/OEM embedding into equipment
• Mounting: designed for mechanical integration inside devices
• Application: barcode reading for automated systems and point-of-service

How to use

Install the Datalogic M34 module into the designated mounting location within the host device, aligning the scanning window with the external opening or the target barcode presentation area. Secure the module mechanically according to the equipment design and connect the DSUB interface to the host electronics using the appropriate mating cable or connector. After electrical connection, configure the host system or the scanner firmware settings as required for barcode symbologies and communication parameters. Perform functional tests with representative barcodes to verify correct read range, orientation, and data transmission.
