Reflector Datalogic Reflektor R2 Rund 86 x 63 x 8 mm (S940700048)

Datalogic Reflektor R2 rund 86 x 63 x 8 mm is an optical reflector designed to work with compatible photoelectric sensors. The reflector returns emitted light to the sensor, enabling reliable presence/absence detection and interruption sensing in industrial automation environments. Its compact round shape and thin profile make it suitable for installation in confined spaces and for use on conveyors and sensor alignment fixtures.

Advantages

The reflector offers a durable reflective surface engineered for consistent light return, helping to stabilize sensor switching and reduce false triggers. Its small footprint and slim 8 mm thickness simplify mounting and integration into existing sensor setups. The round design supports a range of alignment angles, improving ease of installation and maintenance in production lines.

Suitable for

• Presence/absence detection with retro-reflective photoelectric sensors
• Interruption sensing on conveyor belts and sortation systems
• Sensor alignment and calibration in machine vision or automation cells
• Compact installations where space is limited

Key specifications

• Shape: round reflector
• Dimensions: approximately 86 x 63 x 8 mm
• Thickness: 8 mm
• Intended use: retro-reflective operation with photoelectric sensors
• Material surface: reflective coating suitable for optical return

How to use

Mount the reflector opposite the photoelectric sensor so that the sensor’s emitter and receiver align with the reflector surface. Ensure the reflector is clean and free of obstructions to maintain reliable light return. Adjust the sensor alignment and distance according to the sensor manufacturer’s recommendations to achieve the desired switching range and response. Regularly inspect the reflector surface and clean with a soft cloth to prevent dust or debris from affecting performance.

Usage recommendations

For best results, use the reflector with sensors rated for retro-reflective operation and follow the sensor’s alignment procedure. Avoid mounting locations exposed to direct mechanical impact or heavy contamination; if operating in dusty or oily environments, verify switching performance regularly and clean the reflector as needed to maintain reliable detection.
