Relay Dedra JQX-76F-UT-2A 14A 230V — electromagnetic switching relay

The Dedra JQX-76F-UT-2A is an electromagnetic power relay with a 230 V coil and a single-pole contact designed for switching AC loads up to 14 A. Intended for control and automation applications, it fits into relay modules, control panels, timers, and simple household or light industrial circuits where a compact electromechanical switching device is required. Its construction provides reliable mechanical isolation between coil and contact circuits and enables straightforward integration into systems that require a 230 V control signal to switch mains loads.

Advantages

The relay offers a clear functional design with a 230 V coil and 14 A contact rating that suits common mains switching tasks. As an electromechanical device, it provides physical contact separation which is useful for electrical isolation and simple fault diagnostics. The single-pole switching arrangement and standard footprint allow compatibility with many existing sockets and relay modules, enabling easy replacement or integration without complex rewiring.

Suitable for (tasks / use cases)

• Switching resistive and moderate inductive AC loads up to 14 A at 230 V
• Integration in control panels, relay modules, and timer circuits
• Basic automation tasks in household and light industrial environments
• Load switching where mechanical isolation between control and power circuits is required

When it may not be suitable

This relay is not intended for high-current industrial loads that exceed its 14 A contact rating or for direct switching of large motors or heavy inductive loads without appropriate surge protection. It also may not be suitable where solid-state switching, very high switching frequencies, or silent operation are required, since electromechanical relays produce audible click sounds and have mechanical wear over time.

Key specifications

• Coil nominal voltage: 230 V AC
• Contact configuration: single pole (SPST)
• Contact current rating: 14 A at 230 V AC
• Intended switching type: AC mains loads (resistive and moderate inductive)
• Mounting: panel or relay socket compatible footprint
• Operation principle: electromagnetic (electromechanical) switching

How to use

Install the relay into a compatible socket or mount it securely in the control panel according to the panel layout. Connect the coil terminals to a 230 V control supply, observing correct polarity and safety practices for AC mains wiring. Wire the load through the relay's common and normally open (or normally closed) contact terminals depending on desired switching logic. Ensure that wiring is secured, that protective devices (fuses or circuit breakers) are in place for the controlled circuit, and that any necessary snubber or surge suppression is fitted when switching inductive loads.

What to consider before purchase

• Verify that the 14 A contact rating at 230 V AC is sufficient for the load to be switched.
• Confirm compatibility with the control voltage (230 V AC coil) used in your system.
• Check available space and mounting or socket type for physical fit.
• Plan for surge suppression or RC snubbers when switching inductive loads or motors.

Usage recommendations

Use the Dedra JQX-76F-UT-2A for routine mains switching where electromechanical isolation is desired, pair it with appropriate overcurrent protection and suppression components for inductive loads, and follow standard electrical safety practices during installation and maintenance.
