EFB Elektronik 28656.1 D-Sub 15-pin Connector Grey

The EFB Elektronik 28656.1 is a professional-grade 15-pin D-Sub connector engineered for stable and reliable signal transmission in diverse electronic systems. Constructed with a robust tin-plated housing, this connector is designed to withstand the demands of industrial and computing environments while maintaining signal integrity. Its neutral grey aesthetic and standardized design make it a versatile component for both new hardware assemblies and the repair of existing interface connections.

Advantages

This D-Sub connector offers exceptional durability due to its high-quality tin-plated housing, which provides effective protection against environmental factors and mechanical wear. With a quality level rated for at least 50 mating cycles, it ensures consistent performance and secure contact reliability over repeated use. The 15-pin configuration is widely compatible with standard hardware interfaces, facilitating seamless integration into professional electronic setups and maintenance projects.

Suitable for

• Industrial automation and control systems
• Computing hardware and peripheral interface repairs
• Custom electronic cable assembly
• Data transmission and signal routing applications

This connector may not be suitable for high-vibration environments where locking mechanisms beyond standard friction fit are required, or for applications involving extreme moisture or corrosive chemical exposure without additional protective housing. It is also not intended for high-power electrical distribution tasks.

Key specifications

• Connector type: 15-pin D-Sub
• Housing material: Tin-plated
• Durability: Minimum 50 mating cycles
• Color: Grey

To use this connector, ensure that the cable wires are properly stripped and soldered or crimped to the corresponding pins according to your specific wiring diagram. Once the connections are secured, the connector can be inserted into the matching D-Sub port on your hardware. Ensure the connection is fully seated to maintain stable signal transmission.

What to consider before purchase

• Verify the pin count matches your existing hardware interface
• Check if your assembly requires a specific gender or mounting hardware
• Ensure the cable gauge is compatible with the connector terminals

Usage recommendations: Always perform a continuity test after assembly to ensure all pins are correctly connected and free from short circuits. Keep the connector clean and free of debris to maximize the lifespan of the contact pins.
