Wire connector Dsub 9-pin EFB Elektronik 29226.2 Black

The EFB Elektronik 29226.2 is a D-sub 9-pin female wire connector in black designed for reliable electrical connections in electronic equipment. With a compact housing that measures 30.8 mm in width, 12.5 mm in depth and 18.4 mm in height, this connector is intended for installation where space is limited and a durable, standard D-sub interface is required. The single-piece pack includes one female connector suitable for cable termination and panel wiring tasks.

Advantages

This D-sub 9-pin female wire connector offers a standard 9-pin layout compatible with many serial and control interfaces, while the compact dimensions allow integration into tight assemblies. The connector's black housing provides basic mechanical protection and a neutral appearance. It is built for repeated mating cycles and stable contact retention, supporting consistent signal and low-voltage power transmission in typical electronic applications.

Suitable for

• Serial communication interfaces (RS-232/RS-422/RS-485) and similar signal connections
• Industrial control panels and instrumentation
• Small electronic devices and embedded systems requiring a D-sub 9 connector
• Repair or replacement of existing D-sub 9 female terminations

Key specifications

• Connector type: D-sub (female), 9-pin configuration
• Housing color: black
• Width: 30.8 mm
• Depth: 12.5 mm
• Height: 18.4 mm
• Package quantity: 1 piece

How to use

Prepare the cable and wires according to the intended wiring scheme, ensuring correct pin assignment for signals and ground. Insert and solder or crimp each conductor to the corresponding contact point following standard D-sub 9 wiring conventions. After wiring, assemble the connector housing if applicable and secure the connector in the device or panel using the appropriate mounting hardware. Verify continuity and correct pin mapping with a multimeter before applying power or connecting to external equipment.

Usage recommendations

Use this connector in environments within normal indoor operating conditions and avoid exposure to excessive moisture, corrosive atmospheres, or mechanical stress. For reliable long-term performance, ensure proper strain relief on cables and avoid repeated forceful insertions that may damage contacts.
