Wire connector Dsub 26-pin EFB Elektronik 34509.1

The EFB Elektronik 34509.1 is a 26‑pin D‑sub male wire connector in silver finish designed for reliable signal and low‑power connections in electronic equipment. With a compact housing measuring 30.8 mm wide, 12.5 mm deep and 11.6 mm high, this connector fits space‑constrained panels and assemblies while providing a standardized D‑sub interface for cabling and wiring tasks. Supplied as a single piece, it is suitable for prototyping, repair and small production runs where a robust mechanical and electrical connection is required.

Advantages

This D‑sub 26‑pin connector offers a compact form factor that saves panel space and simplifies cable routing. Its silver finish ensures good conductivity and corrosion resistance appropriate for general electronic applications. The male pin configuration provides a stable mating with corresponding female connectors and DB‑26 housings. The product’s standardized dimensions make it compatible with common D‑sub mounting and cable assemblies, enabling straightforward replacement or integration.

Suitable for

• Signal wiring and low‑power connections in control panels and instruments
• Repair and replacement of existing D‑sub 26‑pin interfaces
• Prototyping and small batch electronics assemblies
• Cable assemblies where a compact 26‑pin male connector is required

Key specifications

• Connector type: D‑sub male, 26 pins
• Finish/color: Silver
• Dimensions (W × D × H): 30.8 mm × 12.5 mm × 11.6 mm
• Packaging: single piece per pack
• Suitable for standard D‑sub mating housings and cable assemblies

How to use

Install the connector by aligning the male pins with the mating female header or cable assembly and secure according to the device’s mounting method. For panel mounting, ensure the cutout and screw positions conform to the equipment’s mechanical design. Terminate wires to the connector pins following the wiring diagram or schematic, using appropriate soldering or crimping techniques compatible with the connector style. Verify pin continuity and correct wiring before powering the system.

Usage recommendations

Use the connector in environments free of excessive moisture and corrosive chemicals. Apply appropriate strain relief and cable management to reduce mechanical stress on soldered or crimped joints. When replacing existing connectors, match pinouts and verify mechanical fit to avoid damage to mating parts.
