Wire Connector EFB Elektronik 34605.1 Dsub 50-pin Black

The EFB Elektronik 34605.1 D-sub wire connector is a black, 50-pin female connector designed for reliable signal and low-power connections in electronic equipment. Supplied as a single piece, this compact D-sub connector is intended for use where a secure multi-pin interface is required, such as control panels, measurement instruments, and communication devices. The connector's form factor and contact arrangement follow standard D-sub conventions to ensure compatibility with mating connectors and cable assemblies.

Advantages

This 50-pin D-sub female connector provides stable electrical contact and straightforward installation in compact assemblies. Its standard D-sub shape supports reliable mating with male counterparts and minimizes the risk of bent pins during connection. The black housing offers a neutral appearance that integrates easily into a variety of equipment designs, while the single-piece packaging suits one-off repairs or small batch projects.

Suitable for

• Signal and low-voltage connections in industrial control systems
• Repair and replacement of D-sub interfaces on measurement and test equipment
• Custom cable assemblies and connectorization for communication devices
• Prototyping and small-scale electronic projects requiring a 50-pin interface

Key specifications

• Connector type: D-sub (female), 50 pins
• Color: black
• Application: multi-pin signal and low-voltage connections
• Packaging: single piece
• Mounting style: cable/inline connector (intended for wire/cable termination)

How to use

Prepare cable conductors according to the wire gauge and insulation requirements appropriate for the application. Terminate each conductor to the corresponding female contact following the pinout diagram of the device or cable assembly. Ensure that contacts are fully seated and that the connector housing is assembled correctly to provide strain relief. When mating with a male D-sub connector, align the shell and pins carefully to avoid damage. Tighten any fastening screws or securing mechanisms to maintain a stable connection during operation.

Usage recommendations

Verify the pinout and signal types before installation to prevent cross-connection. Use suitable crimping or soldering tools compatible with the connector contacts and follow ESD precautions when handling electronic components. For long-term installations, check the connection periodically for corrosion or loosening and replace the connector if mechanical or electrical integrity is compromised.
