Module panel 3U/14HP by EFB Elektronik for 12 × SC Duplex (unpopulated) - rack accessory

EFB Elektronik module panel, 3U (3HE) high and 14HP (14TE) wide, designed to accept up to 12 SC Duplex adapters. The front plate is made of aluminium and is supplied unpopulated so you can install SC Duplex couplers or adapters to suit your fibre cabling. The panel includes a labelling strip and an aluminium mounting plate that can accommodate a splice cassette and an overlength cassette; it is intended for rack-mounted use to organise and protect fibre terminations and simplify patching and cable management.

Advantages

The aluminium 3U/14HP front plate provides a rigid and corrosion-resistant mounting surface while keeping the panel lightweight. The unpopulated design allows flexible adapter selection and placement for different cabling layouts. Integrated fixing points with screws ensure secure module attachment, and the included labelling strip enables clear port identification. An aluminium mounting plate supports a splice cassette and an overlength cassette for neat fibre handling, and an integrated strain relief secures the central tube to reduce stress on fibres.

Suitable for (tasks / use cases)

• Rack-mounted fibre distribution in server rooms and network cabinets
• Termination and patching of up to 12 SC Duplex fibre connections
• Organising fibre infrastructure where splice and overlength cassettes are required
• Retrofit projects requiring custom selection of adapters or couplers

Key specifications

• Brand: EFB Elektronik
• Model / MPN: 53711.24
• EAN: 4049759103279
• Height: 3U (3HE)
• Width: 14HP (14TE)
• Material: Aluminium front plate and mounting plate
• Capacity: up to 12 × SC Duplex adapters (unpopulated)
• Included: labelling strip, aluminium mounting plate with splice cassette and overlength cassette support
• Module fixing: screw mounting
• Integrated strain relief for central tube

How to use

Mount the module panel into a compatible 19" rack or cabinet at the desired 3U location. Install SC Duplex adapters or couplers into the front plate according to your patching plan, securing each module with the provided screw fixing points. Fit the splice cassette and overlength cassette onto the aluminium mounting plate as required, route fibres through the central tube and secure them with the integrated strain relief to prevent tension on fibre joints. Label ports using the supplied labelling strip for clear identification.

Usage recommendations

For reliable fibre performance, perform terminations and splices in a clean environment and follow standard fibre handling practises. Ensure sufficient bend radius for all fibres and secure the central tube with the integrated strain relief to minimise mechanical stress. Use compatible SC Duplex adapters and cassettes to match your existing infrastructure.
