header-product Elo Touch Solutions 1004L Digital signage flat panel 25.6 cm (10.1") LED 400 cd/m² WXGA Black

Elo Touch Solutions 1004L Digital signage flat panel 25.6 cm (10.1") LED 400 cd/m² WXGA Black

Elo Touch Solutions 1004L E315290 Photo 1
Elo Touch Solutions 1004L E315290 Photo 2
Elo Touch Solutions 1004L E315290 Photo 3
Elo Touch Solutions 1004L E315290 Photo 4
Elo Touch Solutions 1004L E315290 Photo 5
Elo Touch Solutions 1004L E315290 Photo 6
Energy label
Elo Touch Solutions 1004L E315290 Photo 1
Elo Touch Solutions 1004L E315290 Photo 2
Elo Touch Solutions 1004L E315290 Photo 3
Elo Touch Solutions 1004L E315290 Photo 4
Elo Touch Solutions 1004L E315290 Photo 5
Elo Touch Solutions 1004L E315290 Photo 6
Energy label

Short description

Elo Touch Solutions 1004L. Product design: Digital signage flat panel. Display diagonal: 25.6 cm (10.1"), Display technology: LED, Display resolution: 1280 x 800 pixels, Display brightness: 400 cd/m², HD type: WXGA. Product colour: Black
Warranty: 2 Years
SKU: 11504869
delivery
Information regarding the items availability for purchase will be posted on this site
price
Item cost information will be published on this site
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

Elo Touch Solutions 1004L. Product design: Digital signage flat panel. Display diagonal: 25.6 cm (10.1"), Display technology: LED, Display resolution: 1280 x 800 pixels, Display brightness: 400 cd/m², HD type: WXGA. Product colour: Black

Key Features

  • Scratch-resistant glass surface
  • IP54 sealed design
  • IK07 impact resistant
  • 50,000 MTBF
  • Digital signage flat panel Black
  • 25.6 cm (10.1") 1280 x 800 pixels LED 400 cd/m²
  • 60 Hz 30 ms
  • Built-in speaker(s) 4 W
The 1004L touchmonitor delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity. With state-of-the-art optical bonding and IP54-sealed design, the 10” touch monitor offers a feature-rich platform and the versatility to extend across a diverse range of applications from point-of-sale, self-service and kitchen display systems to warehouse automation, access control and HMI.

Create the perfect payment stack with the 10" touchscreen.
Easily pair the 10-inch touchscreen monitor with one of Elo's integrated payment devices - from Elo Pay mobile computers to the Elo Pay 7", the 1004L offers the perfect compact touch display with the connectivity you need at the point of sale.

State of the art optical viewing.
Designed with high quality optical bonding, anti-
glare coverglass and low-blue light settings -
the 1004L 10-inch touch­screen monitor brings
the best-in-class solution for viewing comfort
and clarity.

Secure your cables into place.
Never lose your port covers and screws with the security of the
captive design. With a port cover that locks into place, cables are
less prone to becoming disconnected, resulting in minimal
disruptions to the device.

Connect accessories to the edge.
Elo Edge Connect™ offers an expansive lineup of accessories that seamlessly attach to the edge of the display including - EMVs, barcode scanners, status lights, cameras, RFID, MSR, fingerprint scanner and more.

Navigate the OSD directly on the touchscreen.
The on-screen display (OSD) controls are now directly on the touchscreen - making navigation easier while still offering OSD lock security.

Expand the possibilities with touch through.
Elo's TouchPro PCAP monitors feature touch through capability, supporting use with gloves and additional layers of films and filters to meet specific industry requirements.

Get peace of mind with EloCare
From advance unit replacement to extended warranties, EloCare delivers service and support from the people who know your Elo products best.

Quality that is built to last.
We engineer each product with a goal that goes beyond meeting expectations; we aim to exceed them. By integrating our technology into your operations, you are partnering with us - and as your partner, we are committed to delivering reliable products so you can focus on growth and innovation, confident in the knowledge that we stand behind our products, ready to support you every step of the way.

Specifications

Display diagonal: Size of the display for this product, measured diagonally, usually in inches.
10.1 "
Display resolution: The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
1280 x 800
HD type: Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
WXGA
Panel type:
TFT-LCD
Display technology: The technology used in the display e.g. plasma, LED.
LED
Power consumption (typical): Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
6.5 W
Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.
D
VESA mounting:
Yes
Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
No
DisplayPorts quantity: Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
DVI port: Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
No
HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
Product design: The creation of a plan or convention for the construction of an object or a system.
Digital signage flat panel
Purpose: What the product is used for.
Universal
Touchscreen: A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
No
Native aspect ratio: The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
16:10
Built-in speaker(s): The device contains speaker(s) to produce sound.
Yes
Product colour: The colour e.g. red, blue, green, black, white.
Black
All features

Other features

USB connector type: The type of USB connector/port that this product has.
USB Type-C, Micro-USB
International Protection (IP) code: The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
IP54

Operational conditions

Storage relative humidity (H-H):
10 - 95
Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.
-20 - 60
Operating relative humidity (H-H):
20 - 80
Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.
0 - 40

Packaging content

Cables included:
USB Type-A to USB Type-C, Power, HDMI

Packaging data

Package weight: Weight of the packaged product.
2200 g
Package height: The distance from the top to the bottom of the packaging.
223 mm
Package depth: The distance from the front to the back of the packaging.
143 mm
Package width: The distance from one side of the packaging to the other.
308 mm

Weight & dimensions

Display weight:
900 g
Display height:
25 mm
Display depth:
168 mm
Display width:
249 mm

Power

Energy efficiency scale: Range of energy efficiency levels classifying devices from most to least energy-efficient.
A to G
Energy consumption (SDR) per 1000 hours: Power consumption in switched-on state expressed in W.
7 kWh
Power consumption (off):
0.25 W
Power consumption (sleep):
1 W
Power consumption (typical): Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
6.5 W
Energy efficiency class (SDR): Energy efficiency class is a standard classification that is used all over Europe and which is understandable at first sight. Products can be efficiently compared according to classes, starting from A (the most energy efficient class), and ending with G (the most energy-intensive class). The classification of energy efficiency is based on annual energy consumption which is being calculated on the basis of several different parameters.
D

Ergonomics

VESA mounting:
Yes

Network

Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
No

Ports & interfaces

USB port: The device features a socket into which a USB cable can be plugged.
Yes
DC-in jack: The socket/plug where the DC electricity supply connects to the device.
Yes
USB Power Delivery up to:
18 W
USB Power Delivery (USB PD):
Yes
USB ports quantity:
1
DisplayPorts quantity: Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
DVI port: Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
No
Mini HDMI ports quantity: The new HDMI mini connector, next to the regular HDMI connector, is designed to be used with small portable devices such as camcorders and digital still cameras.
1
HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1

Design

Panel mounting interface: The product can be used wih VESA mounting interfaces.
75 x 75
Screen shape:
Flat
Orientation:
Horizontal/Vertical
Product colour: The colour e.g. red, blue, green, black, white.
Black
Product design: The creation of a plan or convention for the construction of an object or a system.
Digital signage flat panel

Performance

Mean time between failures (MTBF): Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
50000 h
On Screen Display (OSD):
Yes
On Screen Display (OSD) languages:
ITA, JPN, FRE, ESP, ENG, DEU, CHI (TR), CHI (SIMPL)
Purpose: What the product is used for.
Universal

Display

Horizontal scan range:
30 - 80
Native refresh rate:
60 Hz
Number of displays:
1
Display diagonal (metric): This is the size of the display screen, measured diagonally.
26 cm
Active display area (W x H):
217 x 135.6
Display number of colours:
16.7 million colours
Viewing angle, vertical: Maximum vertical angle at which a display can be viewed with acceptable visual performance.
170 °
Viewing angle, horizontal: Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
170 °
Contrast ratio (typical): The difference in light intensity between the brightest white and the darkest black.
800:1
Response time: The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)
30 ms
Touchscreen: A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
No
Anti-glare screen: Always gives an optimal view, even in direct sunlight.
Yes
Display brightness: Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.
400 cd/m²
Panel type:
TFT-LCD
HD type: Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
WXGA
Display technology: The technology used in the display e.g. plasma, LED.
LED
Display diagonal: Size of the display for this product, measured diagonally, usually in inches.
10.1 "
Native aspect ratio: The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
16:10
Display resolution: The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
1280 x 800

Audio

RMS rated power: RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.
4 W
Number of built-in speakers:
2
Built-in speaker(s): The device contains speaker(s) to produce sound.
Yes
