Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.059 kg
-
Package weight:
Weight of the packaged product.
-
144 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-10 - 55
-
Height:
The measurement of the product from head to foot or from base to top.
-
33 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
230
-
Width:
The measurement or extent of something from side to side.
-
54 mm
-
Depth:
The distance from the front to the back of something.
-
41 mm
-
Power consumption (standby):
The amount of electricity that is consumed when the product is on standby.
-
0.25 W
-
Channels quantity:
The number of channels the device has. There can be an individual input or output for each channel.
-
1 channels
-
Input frequency:
The frequency (Hz) which is required to power the product.
-
50
-
Package depth:
The distance from the front to the back of the packaging.
-
122 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
48 mm
-
Package width:
The distance from one side of the packaging to the other.
-
122 mm
-
Mounting type:
Type of mounting e.g. wall mounting.
-
Flush-mounted
-
Remotely operated:
The device can be controlled by remote control, which is a device that controls an apparatus by means of radio or infrared signals.
-
Yes
-
Current:
-
16 A
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP20
-
Maximum outdoor range:
The maximum distance to which the signals are transmitted, when the device is used outdoors.
-
180 m
-
Frequency:
-
869.65 MHz
-
Product type:
The sub-category of the product.
-
Switching actuator
-
Maximum switching capacity:
-
3220 W
