Interface:
Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2.
-
RJ-45
-
Type:
Characteristics of the device.
-
IP security camera
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.5 kg
-
Operating relative humidity (H-H):
-
10 - 90
-
Cabling technology:
Type of cable technology performance.
-
10/100/1000Base-T(X)
-
Package weight:
Weight of the packaged product.
-
1000 g
-
Form factor:
The shape or design of the product.
-
Covert
-
Built-in microphone:
Microphone that is found inside the product.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 60
-
Camera shutter speed:
Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
-
1/5 to 1/20,000s
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Height:
The measurement of the product from head to foot or from base to top.
-
90 mm
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Minimum illumination:
Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
-
0.01 lx
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 1.7
-
Width:
The measurement or extent of something from side to side.
-
200 mm
-
Depth:
The distance from the front to the back of something.
-
200 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
4000 x 3000
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
White
-
LED type:
-
IR
-
Bluetooth:
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
-
No
-
Video compression formats:
-
H.264
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Microphone in:
The socket where a microphone is connected to the device.
-
Yes
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
Yes
-
Noise reduction:
-
Yes
-
Full HD:
Full High Definition (HD) means that a display supports a resolution of 1920 x 1080 pixel, and has a digital TV connection.
-
Yes
-
Progressive scan:
Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
-
Yes
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Indoor & outdoor
-
Frame rate:
-
25 fps
-
Web-based management:
Using a website/web application to manage something.
-
Yes
-
Reset button:
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
200 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
90 mm
-
Package width:
The distance from one side of the packaging to the other.
-
200 mm
-
Quick installation guide:
-
Yes
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Fixed focal length:
-
1.8 mm
-
Password protection type:
-
User
-
Video motion detection:
-
Yes
-
Active tampering alarm:
-
Yes
-
3G:
Third generation of mobile telecommunications technology, 3G finds application in wireless voice telephony, mobile Internet access, fixed wireless Internet access, video calls and mobile TV.
-
No
-
Ethernet interface type:
-
Gigabit Ethernet
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Power source type:
What the power source is.
-
PoE
-
Camera shutter type:
Indicates if the camera shutter is mechanical or electronic.
-
Electronic
-
Total megapixels:
A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
-
12 MP
-
Image quality adjustment:
-
Brightness
-
Protection features:
Physical effects from which the product is protected e.g. water resistant, crash proof.
-
Vandal proof
-
Built-in HDD:
The product has a hard drive built into it.
-
No
-
Night vision distance:
-
15
-
Field of view (FOV) angle:
-
360 °
-
Wide Dynamic Range (WDR):
-
Yes
-
Infra-red wavelength:
-
850 nm
-
Day/night mode:
-
Yes
-
Number of cameras:
The quantity of cameras that product can support.
-
1
-
Power consumption (max):
The maximum amount of power used by the device.
-
9 W
-
IK code:
-
IK10
-
Weatherproof:
-
Yes
-
Video streaming:
-
Yes
-
Password protection:
The computer, smartphone etc. can only be used when the correct password is entered, therefore making it more secure.
-
Yes
-
4G:
Fourth generation of mobile phone mobile communication technology standards. A 4G system provides mobile ultra-broadband Internet access, for example to laptops with USB wireless modems, to smartphones, and to other mobile devices. Conceivable applications include amended mobile web access, IP telephony, gaming services, high-definition mobile TV, video conferencing, 3D television, and cloud computing.
-
No
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
9 W
-
Privacy protection:
-
Yes
-
Infrared (IR) cut-off filter:
-
Yes
-
3D NR (Noise Reduction):
-
Yes
-
Smart IR:
-
Yes
-
Noise reduction technology:
-
3D noise reduction
-
Heartbeat:
-
Yes
-
Works with Apple HomeKit:
HomeKit is a software framework by Apple that lets users set up their iPhone or other Apple device to configure, communicate with, and control smart-home appliances. By designing rooms, items and actions in the HomeKit service, users can enable automatic actions in the house through a simple voice dictation to Siri or through apps
-
No
-
Camera pan control:
-
No
-
Works with the Google Assistant:
The Google Assistant is a virtual assistant developed by Google that is primarily available on mobile and smart home devices. Unlike Google Now, the Google Assistant can engage in two-way conversations
-
No
-
Megapixels per lens:
-
12 MP
-
Built-in SSD:
-
No
