HDD capacity:
The maximum storage capacity of the hard disk, usually measured in bytes e.g. GB.
-
1000 GB
-
Dimensions (WxDxH):
Dimensions of the product (Width x Depth x Height).
-
504 x 432.4 x 88
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
10 kg
-
Internal memory type:
The type of internal memory such as RAM, GDDR5.
-
DDR5-SDRAM
-
Rack mounting:
The type of mounting that can position devices in a shelving system (rack).
-
Yes
-
Chassis type:
The type of rigid framework onto which is the hosuing for device components.
-
Rack
-
Package weight:
Weight of the packaged product.
-
12000 g
-
Processor manufacturer:
The manufacturer that produced the processor.
-
Intel
-
Power supply:
The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable.
-
550 W
-
Motherboard form factor:
Design of the motherboard (ATX, BTX etc).
-
Micro ATX
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Hot-swap HDD bays:
Hot-swap hard drives are drives that can be removed and replaced during operation. Hot-swap hard drives are placed into hot-swap hard drive bays inside computers.
-
No
-
Maximum internal memory:
The maximum internal memory which is available in the product.
-
256 GB
-
Height:
The measurement of the product from head to foot or from base to top.
-
210 mm
-
RAID controller type:
-
Software
-
ECC:
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
-
No
-
Width:
The measurement or extent of something from side to side.
-
570 mm
-
Depth:
The distance from the front to the back of something.
-
690 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Cables included:
-
Power
-
Internal drive bays:
-
4
-
USB 2.0 ports quantity:
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
-
3
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
2
-
Processor socket:
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
-
LGA 1851 (Socket V1)
-
Compatible operating systems:
List of desktop operating systems tested as compatible with this product.
-
Windows 11
-
Number of SATA connectors:
-
4
-
Operating system installed:
Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.
-
Windows 11 Pro
-
Redundant power supply (RPS) support:
Additional power supply which can run a computer if the main power supply fails.
-
Yes
-
Total storage capacity:
The total amount of data that can be stored on the device.
-
1000 GB
-
Number of HDDs supported:
The total number of hard drives that can be used in/with this product.
-
4
-
HDMI ports quantity:
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
-
1
-
Trusted Platform Module (TPM):
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
690 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
210 mm
-
Package width:
The distance from one side of the packaging to the other.
-
570 mm
-
HDMI version:
-
2.1
-
SSD interface:
The type of interface(s) with which the Solid State Drive is connected to other hardware.
-
PCI Express
-
SSD capacity:
-
1000 GB
-
Processor cores:
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
-
10
-
PCI Express x4 slots:
-
1
-
Cooling type:
The method used to cool the device or to cool the air around the device.
-
Active
-
DisplayPorts quantity:
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
-
1
-
Supported HDD sizes:
The size of the hard disk drives which can be used by the device.
-
3.5
-
RAID support:
The device uses RAID, which is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required.
-
Yes
-
Processor threads:
-
10
-
Ethernet interface type:
-
25 Gigabit Ethernet
-
Memory slots (available):
-
4
-
Number of 5.25" bays:
A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 5.25" drive bay, also known as full-height bays, were found in old PCs in the early to mid-1980s. They were 3¼″ high by 5¾″ wide, and up to 8″ deep (83 × 146 × 200 mm), used mainly for hard disks and floppy disk drives.
-
2
-
Number of SSDs installed:
-
1
-
Number of SATA III connectors:
Serial ATA (Advanced Technology Attachment) (SATA) is a computer bus interface that connects host bus adapters to mass storage devices such as hard disk drives and optical drives. SATA III (revision 3.x) interface, formally known as SATA 6Gb/s, is a third generation SATA interface running at 6.0Gb/s. The bandwidth throughput, which is supported by the interface, is up to 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface.
-
4
-
On-board graphics card model:
"Graphic adapter" is the hardware that produces images on a display. "On-board" means that the graphics adapter is intergrated inside the motherboard.
-
Intel® Graphics
-
On-board graphics card:
Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.
-
Yes
-
Processor cache:
-
20 MB
-
Trusted Platform Module (TPM) version:
-
2.0
-
Rack rails:
-
No
-
Integrated BMC with IPMI:
-
No
-
Memory layout (slots x size):
The slots and size of the memory for the CPU.
-
1 x 16
-
Internal memory:
A computer's memory which is directly accessible to the CPU.
-
16 GB
-
Number of main power supplies:
The quantity of main power supplies for this product.
-
1
-
Number of redundant power supplies supported:
-
2
-
Number of redundant power supplies installed:
-
1
-
Thermal Design Power (TDP):
-
65 W
-
Operating system language:
-
Multilingual
-
Number of SSDs supported:
-
3
-
Supported storage drive interfaces:
-
M.2
-
Integrated LAN:
-
Yes
-
On-board graphics card 4K support:
-
Yes
-
Processor cache type:
-
Smart Cache
-
Chassis dimensions:
-
503.9 x 432.3 x 87.9
-
3.5" HDD support:
-
4
-
Number of displays supported (on-board graphics):
The feature may not be available on all computing systems. Functionality, performance, and other benefits of this feature may vary depending on system configuration.
-
2
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
-
4
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
-
2
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.
-
1
-
Discrete graphics card:
-
No
-
NVMe:
NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.
-
Yes
-
On-board graphics card family:
-
Intel® Graphics
-
Memory data transfer rate:
-
4800 MT/s
-
Export Control Classification Number (ECCN):
-
5A992C
-
SSD size:
-
M.2
-
PCI Express x16 (Gen 5.x) slots:
-
1
-
Efficient cores:
-
4
-
Performance cores:
-
6
-
Efficient-core base frequency:
-
2.7 GHz
-
Performance-core base frequency:
-
3.3 GHz
-
Number of LAN controllers:
Number of LAN controllers in the product.
-
2
-
Warranty period:
-
3 year(s)
-
Performance-core Max Turbo Frequency:
-
4.9 GHz
