Mounting Bracket Etipo LG-B60-V1 3-pole Support for 60 mm Busbar Rails (MPN 001341700)

Etipo LG-B60-V1 is a 3-pole mounting bracket designed to support busbar rails with a 60 mm centre-to-centre spacing. Manufactured for use in switchgear, distribution panels and industrial electrical installations, the bracket provides mechanical support and alignment for three-pole busbar systems, helping to maintain correct positioning and reduce strain on connections.

Advantages

The bracket offers a compact, single-piece solution for securing three adjacent busbar rails at a fixed 60 mm pitch, allowing straightforward installation and stable mechanical fixation. Its design ensures consistent alignment of the conductors and contributes to reduced vibration and mechanical stress in the electrical assembly. The component is suitable for repeated use in modular panel configurations and enables neat routing inside enclosures.

Suitable for

• Switchgear and control panels requiring 3-pole busbar support
• Electrical distribution boards with 60 mm busbar spacing
• Industrial power installations and retrofit projects

Key specifications

• Configuration: 3-pole support for three adjacent busbars
• Centre-to-centre spacing: 60 mm between busbar rails
• Function: mechanical support and alignment for busbar systems
• Typical application environment: switchgear, distribution panels, industrial installations

How to use

Install the mounting bracket at the required positions along the busbar route to maintain a 60 mm spacing between the three conductors. Secure the bracket to the panel or supporting structure using appropriate fasteners and torque settings compatible with the enclosure material and installation standards. Ensure busbars are seated correctly in the bracket supports and re-check alignment and clearances before energising the system.

Usage recommendations

Confirm compatibility with the specific busbar profile and cross-section before installation, follow local electrical codes and recommended torque values for fastening, and perform mechanical and electrical inspections after mounting to verify alignment and secure connections.
