EUROLITE LED Pixel Ball 360° 1m MK2 — flexible RGB pixel strand, 5 segments, 24V DC

The EUROLITE LED Pixel Ball 360° 1m MK2 is a flexible RGB pixel strand engineered for uniform omnidirectional illumination. At one metre in length it integrates five independently addressable segments, each capable of displaying full RGB colour values for dynamic pixel mapping and animated effects. The strand is designed to run on 24V DC and is compatible with common pixel controllers that support standard LED control protocols, making it suitable for a variety of indoor and weather-protected outdoor lighting applications.

Advantages

The flexible construction allows for easy shaping around structures and integration into creative installations. Five individually addressable segments provide fine-grained control over colour and motion effects while operating at 24V DC offers lower voltage drop over length and compatibility with standard power supplies. The 360° pixel design helps achieve even light distribution from any viewing angle, enabling consistent illumination in stage, architectural, and event contexts.

Suitable for

• Stage and theatre lighting accents
• Architectural and facade detailing in weather-protected areas
• Event lighting and dynamic signage
• Art and exhibition installations requiring pixel mapping
• Indoor ambient or decorative lighting with programmable effects

When it may not be suitable

This product is intended for installations that permit protected exposure to the environment; it is not specified for permanent, fully exposed outdoor installations without additional protection. Applications requiring very small pixel spacing or higher resolution than five segments per metre may need alternative products with denser pixel placement.

Key specifications

• Length: 1 metre
• Pixel configuration: 5 independently addressable segments
• Colour model: RGB
• Illumination coverage: 360° omnidirectional
• Operating voltage: 24V DC
• Mounting type: flexible strand suitable for shaping and fixing to surfaces

How to use

Connect the LED Pixel Ball 360° strand to a compatible pixel controller that supports the strand's control protocol and to a 24V DC power supply sized to the length and number of strands in the installation. Route and secure the flexible strand along the intended mounting surface using clips, ties or channels that do not compress the housing. Configure the controller to address the five segments per metre and program desired colour, brightness and animation patterns. Test the installation at low brightness first, then increase to the required level and verify wiring and signal continuity before final commissioning.

What to consider before purchase

• Ensure compatibility of your pixel controller with addressable RGB strands and the control protocol used.
• Confirm available 24V DC power capacity and calculate total current draw for the planned run length and number of units.
• Check environmental conditions and provide additional protection if the installation will be exposed to rain, direct sunlight, or mechanical wear.
• Plan mounting and mechanical support to avoid kinking or overbending the flexible strand.

Usage recommendations

For reliable results, use a controller that allows per-segment addressing and smoothing of animations, and run initial layouts at reduced brightness to verify colour balance. When used outdoors, place the strand in a covered or sealed channel and secure ends and connectors against moisture. Maintain a service loop for easier replacement and avoid sharp bends with radii smaller than recommended by the installer.
