Power supply EXSYS HDR-100-24

The Power supply EXSYS HDR-100-24 is a reliable power supply designed to deliver a total power output of 92 W for various technical applications. Featuring a compact black housing with dimensions of 70 mm width, 54.5 mm depth, and 90 mm height, this unit integrates easily into standard setups where space efficiency is required. It supports a wide AC input voltage range of 85 to 264 V at a frequency of 47 to 63 Hz, ensuring versatile compatibility with different electrical grids. Built-in LED indicators provide clear visual feedback on the power status during operation. For enhanced safety, the device is equipped with built-in protection mechanisms against over voltage, overload, and short circuits, and it meets rigorous safety standards such as UL60950-1, UL508, TUV EN61558-2-16, IEC60950-1, EAC TP TC 004, and BSMI CNS14336-1.

Advantages

This power supply offers high operational reliability through comprehensive protective features including safeguards against over voltage, overload, and short circuits, which help prevent damage to connected equipment. The wide input voltage range allows the unit to adapt to varying grid conditions without performance loss. Its compact dimensions make it highly suitable for installations with limited physical space. Furthermore, the inclusion of diagnostic LED indicators allows users to monitor the operational status at a glance, minimizing downtime and simplifying maintenance routines.

Suitable for

• Industrial automation systems
• Control panel power distribution
• IT and telecommunications equipment
• General electronics projects requiring stable 24V power

When it may not be suitable

This unit is not designed for outdoor environments without an appropriate weatherproof enclosure, as it lacks outdoor protection ratings. Additionally, applications requiring a total power output exceeding 92 W will necessitate a more powerful supply.

Key specifications

• Total power: 92 W
• AC input voltage range: 85 - 264 V
• Input frequency: 47 - 63 Hz
• Color: Black
• Dimensions: 70 mm width, 54.5 mm depth, 90 mm height
• Protection features: Over voltage, overload, short circuit
• Safety approvals: UL60950-1, UL508, TUV EN61558-2-16, IEC60950-1, EAC TP TC 004, BSMI CNS14336-1
• Status indication: LED indicators

How to use

Installation should be performed by qualified personnel in accordance with local electrical codes and safety regulations. Mount the unit securely within a compatible enclosure or panel utilizing the designated dimensions. Connect the AC input lines to the appropriate terminals, ensuring the supply voltage matches the specified input range of 85 to 264 V. Connect the output terminals to your load, verifying correct polarity and ensuring the total power draw does not exceed 92 W. Verify all connections before powering on the system and observe the LED indicators to confirm normal operation.

What to consider before purchase

• Verify that your load requirements do not exceed the 92 W capacity of the power supply.
• Check the physical dimensions to ensure adequate space within your control panel or enclosure.
• Confirm that your input voltage falls within the supported 85 to 264 V range.

Usage recommendations

Always ensure proper ventilation around the unit within your installation enclosure to prevent excessive heat buildup. Periodically inspect the wiring connections and monitor the LED indicators to maintain long-term reliability and safety.
