Roller Shutter Controller FF STR-1, two-button, 1.5 A AC-3, 230 V, 0–10 min timer

FF STR-1 is a two-button roller shutter controller designed for use with 230 V AC-3 motors. It supports motor loads with a rated current of 1.5 A and provides both manual two-button control and an adjustable 0–10 minute timer for automatic raising or lowering of shutters and blinds. The module is intended for integration into standard AC motor circuits in residential or light commercial installations where timed or manual control of roller shutters and venetian blinds is required.

Advantages

The controller combines simple manual operation via two dedicated buttons with an adjustable timer that allows precise control of travel time from 0 to 10 minutes. Its 230 V AC-3 compatibility ensures straightforward connection to common alternating current motor circuits used for roller shutters. The compact functional design focuses on reliable switching of motor loads up to 1.5 A and supports both automatic and manual modes without additional equipment.

Suitable for

• Control of residential roller shutters driven by 230 V AC-3 motors
• Operation of venetian blinds with compatible AC motors
• Light commercial shutter applications requiring timed lowering/raising
• Retrofit installations where simple two-button control is preferred

Key specifications

• Supply voltage: 230 V AC
• Motor type compatibility: AC-3 motor circuits
• Rated switching current: 1.5 A
• Adjustable timer range: 0–10 minutes
• Control interface: two-button manual control plus timer
• Intended use: roller shutters and venetian blinds

How to use

Install the controller into the motor circuit according to applicable electrical safety standards and wiring practices for 230 V AC equipment. Use the two buttons for manual up/down control of the shutter motor; set the timer to the required value within the 0–10 minute range to enable automatic travel time control. Verify correct motor direction and limit settings on the mechanical shutter or motor unit before regular operation. Ensure power is disconnected when performing installation or wiring adjustments.

Usage recommendations

For reliable operation, use the controller with motors whose running current does not exceed the rated 1.5 A and confirm compatibility with AC-3 switching. Regularly check mechanical end stops and motor fastening to avoid excessive load. When used in commercial or heavy-duty contexts, consider selecting equipment with appropriate current ratings and consult an electrician for installation and configuration.
