FSP NP5-B 120 mm CPU air cooler

Name: CPU air cooler FSP NP5-B, POO0000012
Brand: FSP
SKU: 11265312
Price: 24.99 EUR
Availability: OutOfStock

Aquaphor

Filters you can trust. Pure water every day.

CPU air cooler FSP NP5-B, 120 mm fan, HDB bearing, supports LGA1200/LGA1700/AM4/AM5, black

Short description

FSP NP5-B is a 120 mm air CPU cooler with Hydro Dynamic Bearing (HDB) fan, rotational speed 800–1600 RPM and compact dimensions (94×120×151 mm). It weighs 0.59 kg and supports LGA1200, LGA1700, AM4 and AM5 sockets. Designed for standard desktop cooling, it provides reliable heat dissipation for everyday and gaming systems while fitting most mid-tower builds.

Warranty: 2 Years

SKU: 11265312

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

FSP NP5-B is a compact 120 mm air CPU cooler designed for standard desktop and gaming systems. It combines an aluminum alloy heatsink, a 120 mm Hydro Dynamic Bearing (HDB) PWM fan and a low-profile form factor (94 × 120 × 151 mm) to provide effective heat dissipation while maintaining full RAM clearance. The cooler supports modern CPU sockets including LGA1200, LGA1700, AM4 and AM5 and comes in a black finish that integrates with most black PC builds.

Advantages

The NP5-B uses an aluminum alloy design to ensure efficient thermal conductivity and fast heat transfer from the CPU. Its 120 mm HDB fan operates across a controlled RPM range to balance cooling performance and acoustic comfort, and anti-vibration rubber pads reduce vibration noise. The compact dimensions and full RAM clearance make the cooler suitable for most mid-tower cases, while the black coating provides a uniform appearance in black-themed systems. The mounting bracket is designed for straightforward installation on supported sockets.

Suitable for

Everyday desktop systems that require reliable CPU cooling
Mainstream gaming PCs with mid-range thermal loads
Builds where full RAM clearance is needed
Compact mid-tower cases with limited cooler height

Key specifications

Type: Air cooler
Fan diameter: 120 mm
Fan bearing: Hydro Dynamic Bearing (HDB)
Fan speed range: 800–1600 RPM
Noise and airflow characteristics: designed for balanced acoustic and airflow performance
Dimensions (W × D × H): 120 × 94 × 151 mm
Weight: 0.59 kg
Supported processor sockets: LGA1200, LGA1700, Socket AM4, Socket AM5
Colour: Black
Full RAM clearance with compact height

How to use

Prepare the motherboard and CPU socket according to the motherboard manufacturer’s instructions. Position the NP5-B cooler so the base makes direct contact with the CPU integrated heatspreader, apply an appropriate amount of thermal paste if not pre-applied, and secure the cooler using the supplied mounting bracket and fasteners for the target socket. Connect the 4-pin PWM fan header to the motherboard CPU fan connector to enable speed control. Ensure the cooler is installed vertically as intended for optimal heat pipe performance and check clearances for RAM and surrounding components before powering the system.

Usage recommendations

For best results, use a high-quality thermal paste and verify that the fan header in BIOS/UEFI is configured for PWM control to allow automatic fan speed adjustment. Regularly inspect and clean dust from the heatsink fins and fan to maintain airflow. When installing in compact cases, confirm the 151 mm height fits your chassis and that airflow direction aligns with your case fans for efficient exhaust.

Specifications

Type:: Air cooler
Fan diameter:: 120 mm
Weight:: 0.59 kg
Supported processor sockets:: LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
Product colour:: Black

All features

Performance

Type:: Air cooler
Fan diameter:: 120 mm
Supported processor sockets:: LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
Noise level (high speed):: 28 dB
Rotational speed (min):: 800 RPM
Rotational speed (max):: 1600 RPM
Maximum airflow:: 62 cfm
Bearing type:: Hydro dynamic bearing (HDB)
Suitable location:: Processor
Quantity per pack:: 1 pc(s)
Fan static pressure:: 1.8 mmH2O

Design

Product colour:: Black
Number of fans:: 1 fan(s)
Number of heat pipes:: 4
Radiator material:: Aluminum
Illumination LED:: No

Weight & dimensions

Heat pipes diameter:: 6 mm
Weight:: 0.59 kg
Height:: 151 mm
Width:: 94 mm
Depth:: 120 mm
Radiator width:: 48 mm
Radiator depth:: 120 mm
Radiator height:: 151 mm
Fan dimensions (W x D x H):: 120 x 120 x 25

Power

Rated current:: 0.3 A
Rated voltage:: 12 V
