Height:
The measurement of the product from head to foot or from base to top.
-
86 mm
-
Width:
The measurement or extent of something from side to side.
-
150 mm
-
Depth:
The distance from the front to the back of something.
-
140 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
White
-
Cables included:
-
CPU, PCIe, Peripheral (Molex), SATA
-
Purpose:
What the product is used for.
-
PC
-
PCI Express connector:
-
Yes
-
Bearing technology:
-
Hydraulic
-
Input current:
-
12 - 6
-
Number of fans:
The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).
-
1 fan(s)
-
Efficiency:
-
90 %
-
On/off switch:
The button which is pressed to switch the device on or off.
-
Yes
-
Cooling type:
The method used to cool the device or to cool the air around the device.
-
Active
-
Motherboard power connector:
The way in which the motherboard is connected to the power supply.
-
20+4 pin ATX
-
Number of SATA power connectors:
-
6
-
Peripheral (Molex) power connectors (4-pin):
White 4-pinned connector used to connect a peripheral to the power supply.
-
2
-
CPU power connector (4+4 pin):
-
Yes
-
Power protection features:
Features that protect the device against power problems e.g. overload.
-
Over power, Over total voltage, Over voltage, Short circuit, Surge & inrush protection (SIP), Under voltage, Over current, No load operation
-
Fan diameter:
The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan.
-
120 mm
-
Power factor:
-
0.9
-
PCI Express power connectors (6+2 pin):
-
4
-
ATX version:
ATX (Advanced Technology eXtended) is a motherboard form factor specification developed by Intel in 1995. The specification defines the key mechanical dimensions, mounting point, I/O panel, power and connector interfaces between a computer case, a motherboard and a power supply. There are many versions of ATX including ATX12V 1.x and ATX12V v2.3.
-
3.1
-
EPS version:
-
2.92
-
Fan location:
-
Top
-
80 PLUS certification:
-
80 PLUS Gold
-
Power Factor Correction (PFC) type:
-
Active
-
Combined power (+3.3V):
-
100 W
-
Combined power (+12V):
-
1000 W
-
Combined power (+5V):
-
100 W
-
Combined power (-12V):
-
3.6 W
-
Combined power (+5Vsb):
-
15 W
-
Max output current (+3.3V):
-
20 A
-
Max output current (+12V):
-
83.33 A
-
Max output current (+5V):
-
20 A
-
Max output current (-12V):
-
0.3 A
-
Max output current (+5Vsb):
-
3 A
-
AC input frequency:
-
50/60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
Cabling type:
-
Fully-Modular
-
Total power:
The total power that is needed by the device, or the total power produced by the device.
-
1000 W
-
Motherboard power cable length:
-
600 mm
-
SATA power cable length:
-
500, 810, 965, 655
-
CPU power cable length:
-
700 mm
-
Peripheral (Molex) power cable length:
-
810, 965
-
Power supply unit (PSU) form factor:
-
ATX
-
PCI Express power connectors (12+4 pin):
-
1
-
Number of SATA power cables:
-
2
