Type:
-
IP security camera
-
Weight:
-
0.62 kg
-
Certification:
-
EMC:
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471
Environment:
IEC/EN 63000
IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10
-
Power consumption (typical):
Power consumption in switched-on state expressed in W.
-
4.2 W
-
Security algorithms:
-
EAP-LEAP, EAP-PEAP, EAP-TLS, HTTPS, MSCHAPv2
-
Flash memory:
-
256 MB
-
Supported network protocols:
-
IPv4, IPv6
-
White balance:
-
ATW, AWC, Indoor, Manual, Outdoor
-
Operating relative humidity (H-H):
-
0 - 95
-
Compatible memory cards:
-
MicroSD (TransFlash), SDHC, SDXC
-
Storage temperature (T-T):
-
-30 - 55
-
Form factor:
-
Turret
-
Operating temperature (T-T):
-
-30 - 55
-
Camera shutter speed:
-
1/5~1/12000
-
Ethernet LAN:
-
Yes
-
Storage relative humidity (H-H):
-
0 - 95
-
Height:
-
87.4 mm
-
Focal length range:
-
3
-
Sensor type:
-
CMOS
-
Optical sensor size:
-
25.4 / 2.8
-
Connectivity technology:
-
Wired
-
Maximum resolution:
-
2560 x 1440
-
Product colour:
-
White
-
Number of users:
-
6 user(s)
-
Tilt angle range:
-
0 - 75
-
Bluetooth:
-
No
-
Video compression formats:
-
H.264, H.265, M-JPEG
-
Ethernet LAN (RJ-45) ports:
-
1
-
Noise reduction:
-
Yes
-
Pan range:
-
0 - 350
-
Diameter:
-
125 mm
-
Languages support:
-
CHI (SIMPL), CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, TUR
-
Wi-Fi:
-
No
-
Quality of Service (QoS) support:
-
Yes
-
Card reader integrated:
-
Yes
-
Placement supported:
-
Indoor & outdoor
-
Frame rate:
-
30 fps
-
Mirror:
-
Yes
-
Supported graphics resolutions:
-
320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2560 x 1440
-
Housing material:
-
Aluminium, Plastic
-
Maximum aperture number:
-
1.2
-
Night vision:
-
Yes
-
Live view:
-
Yes
-
Fixed focal length:
-
2.8 mm
-
Mounting type:
-
Ceiling
-
Video motion detection:
-
Yes
-
Remotely operated:
-
Yes
-
Maximum memory card size:
-
128 GB
-
Ethernet interface type:
-
Fast Ethernet, Gigabit Ethernet
-
RAM capacity:
-
512 MB
-
International Protection (IP) code:
Device protection rating against dust and water according to the international IP standard.
-
IP66, IP67
-
Power source type:
-
PoE
-
Camera shutter type:
-
Electronic
-
Total megapixels:
-
4 MP
-
Back Light Compensation (BLC):
-
Yes
-
Built-in HDD:
-
No
-
Wide Dynamic Range (WDR):
-
Yes
-
Day/night mode:
-
Yes
-
Number of cameras:
-
1
-
Power consumption (max):
-
7.6 W
-
IK code:
-
IK10
-
Video streaming:
-
Yes
-
Number of lenses:
-
1
-
Flip & mirror:
-
Yes
-
Privacy masking:
-
Yes
-
Power consumption (Power over Ethernet (PoE)):
-
4.2 W
-
Alert notification type:
-
E-mail
-
Number of sensors:
-
1
-
Fixed focus:
-
Yes
-
Bit rate control:
-
Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
-
Streaming method:
-
Multicast, Unicast
-
Observe distance:
-
18.1 m
-
Detect distance:
-
45.3 m
-
Recognize distance:
-
9.1 m
-
Identify distance:
-
4.5 m
-
Noise reduction technology:
-
Smart Super Noise Reduction (SSNR)
-
Anti-flicker:
-
Yes
-
Camera pan control:
-
Yes
-
Camera tilt control:
-
Yes
-
Number of simultaneous live view channels:
-
3 channels
-
Digest authentication:
-
Yes
-
Lens viewing angle, horizontal:
-
97
-
Lens viewing angle, vertical:
-
53
-
Lens viewing angle, diagonal:
-
113
-
Network access storage (NAS):
-
Yes
