Connector Harting Han 3M-agw-QB 09 37 003 0801 – industrial rectangular heavy-duty connector insert

Harting Han 3M-agw-QB 09 37 003 0801 is an industrial rectangular heavy-duty connector insert designed for integration into Han series housings. The insert provides robust contacts for power and signal transmission and is intended for use in demanding industrial environments such as control cabinets, machine tools and panel-mounted interfaces. It is manufactured by Harting and functions as a replaceable module that simplifies wiring, maintenance and field service.

Advantages

The insert delivers reliable electrical contact and mechanical stability under vibration and repeated mating cycles. Its rectangular heavy-duty design allows a compact arrangement of multiple contacts while offering straightforward installation in compatible Han housings. The construction supports quick replacement of the insert module without reworking the entire connector assembly, reducing downtime and easing maintenance tasks.

Suitable for

• Panel and cabinet connections in industrial control systems
• Interfaces on machine tools and production equipment
• Power and signal distribution in automation systems
• Field-replaceable connector modules for maintenance

Key specifications

• Form factor: rectangular heavy-duty insert designed for Han series housings
• Contact function: mixed power and signal contacts for combined transmission
• Mechanical durability: designed for multiple mating cycles and vibration resistance
• Mounting: module-type insert for panel or housing integration
• Environmental suitability: intended for industrial use with resistance to mechanical stress

How to use

Install the insert into a compatible Han series housing following the housing manufacturer’s assembly instructions. Ensure correct alignment of the insert within the housing and secure it according to the housing fastening method. Connect individual wires or cables to the contacts using appropriate crimp or screw terminations as specified for the contact type. Verify torque values and contact seating where applicable, then mate the assembled connector with the complementary half in the panel or cable assembly to establish power and signal connections.

Usage recommendations

For reliable long-term operation, use the insert within systems designed for Han series heavy-duty connectors, perform periodic inspections of contact condition and tightening torque, and replace the insert if contacts show wear or damage. Follow industry safety practices when working with live circuits and consult Harting documentation for detailed assembly instructions and contact-specific wiring methods.
