header-product Wire Connector Harting 09 56 562 7813 D-Sub 78-pin Black Stainless Steel
40.99 €

Wire Connector Harting 09 56 562 7813 D-Sub 78-pin Black Stainless Steel

Wire Connector Harting 09 56 562 7813 Photo 1
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Wire Connector Harting 09 56 562 7813 D-Sub 78-pin Black Stainless Steel

{{email}}
You keep track of price changes

Wire Connector Harting 09 56 562 7813 D-Sub 78-pin Black Stainless Steel

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

The Harting 09 56 562 7813 is a D-Sub 78-pin wire connector made of black stainless steel and thermoplastic resin. It weighs 30.74 g and complies with RoHS standards, ensuring environmental safety. This connector is ideal for reliable electrical connections in various applications.
Available for order: 10 pcs.
Warranty: 2 Years
SKU: 4816711
Manufacturer: Harting
free shipment

Cheapest delivery:

Venipak Locker LV

Pick-up points

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
24.07.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
29.07.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 0.03 kg)
Parcel couriers
Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Latvijas Pasts nodaļa
29.07.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Harting 09 56 562 7813 is a D-Sub 78-pin wire connector designed for reliable electrical connections. It features a wave-soldering termination, a rated current of 2 A per contact, and a male configuration. The body combines glass-fibre filled thermoplastic resin (PBTP) with nickel-plated steel elements, while contacts are made from a copper alloy. The connector is finished in black and complies with RoHS requirements.

Advantages

This D-Sub 78-pin connector offers compact, high-density contact arrangement and stable electrical performance at up to 2 A rated current per contact. The thermoplastic resin housing with glass-fibre reinforcement provides mechanical strength and dimensional stability, while the nickel-plated steel parts improve corrosion resistance. Wave-soldering termination ensures efficient PCB assembly and secure solder joints. The RoHS compliance confirms absence of restricted hazardous substances.

Suitable for

  • Signal and data connections in industrial control equipment
  • PCB-mounted interfaces requiring D-Sub 78-pin male connectors
  • Equipment where wave-solder assembly is used

Key specifications

  • Manufacturer: Harting
  • Manufacturer part number (MPN): 09565627813
  • EAN: 2050006135495
  • Connector type: D-Sub, male
  • Number of contacts: 78
  • Termination: Wave soldering
  • Rated current: 2 A per contact
  • Housing material: Thermoplastic resin, glass-fibre filled (PBTP)
  • Metal parts: Steel, nickel plated
  • Contact material: Copper alloy
  • Colour: Black
  • Weight: 30.74 g
  • RoHS: Compliant

How to use

Mount the connector to the PCB using the wave-solder termination technique following standard soldering profiles for PBTP-compatible components. Ensure correct orientation of the D-Sub male shell and secure the housing during soldering to prevent movement. After soldering, inspect solder joints for continuity and mechanical integrity and verify contact function with appropriate electrical tests before final assembly.

Usage recommendations

Handle the connector with care during assembly to avoid contamination of contacts. Use recommended soldering profiles for wave soldering to prevent damage to the thermoplastic housing, and perform continuity checks and visual inspection after soldering. Store in a dry, dust-free environment to maintain contact reliability.

All features
Weight:
0.0307 kg
Material:
Steel, Thermoplastic resin
Operating temperature (T-T):
-40 - 85
Connector(s):
D-Sub 78-pin
Product colour:
Black, Stainless steel
Voltage:
1000
Current:
2 A
Connector shielding:
Yes
Connector shield material:
Copper alloy
Insertion force:
222 N
Contact resistance:
25 mΩ
Compliance certificates:
RoHS
